Siemens 6RA7086-6KS22

Parameter list 05.05
11-102 SIEMENS AG 6RX1700-0AD76
SIMOREG DC Master Operating Instructions
PNU Description Value range
[Unit]
Steps
No. indices
Factory
setting
Type
See
Change
(Access /
Status)
n042
(2042)
Warning memory [SW 2.0 and later]
Warning memory for flagging warnings that have occurred since the
electronics supply voltage was last switched on.
The contents of the warning memory are lost when the electronics supply
voltage is switched off and can be deleted with U043.
The warnings are displayed in bit code as for r953 to r960
i001: Display of warnings 1 to 16
i002: Display of warnings 17 to 32
i003: Display of warnings 33 to 48
i004: Display of warnings 49 to 64
i005: Display of warnings 65 to 80
i006: Display of warnings 81 to 96
i007: Display of warnings 97 to 112
i008: Display of warnings 113 to 128
See Section 10.2 for the meaning of the individual warnings
Ind: 8
Type: V2
P052 = 2
U043
(2043)
*
Deleting the warning memory [SW 2.0 and later]
Settings:
0 Deletes the entire warning memory n042 by resetting it to 0.
Subsequently the parameter is automatically set back to value
1.
1 Not active
0 to 1
1
Ind: none
FS=1
Type: O2
P052 = 3
U044
(2044)
*
(G121)
Connector display, decimal [SW 2.0 and later]
Selects those connectors whose value is to be displayed as a decimal with
n045
i001: Selects the connector to be displayed with n045.01
i002: Selects the connector to be displayed with n045.02
i003: Selects the connector to be displayed with n045.03
i004: Selects the connector to be displayed with n045.04
i005: Selects the connector to be displayed with n045.05
All connector
numbers
1
Ind: 5
FS=0
Type: L2
P052 = 3
P051 =40
online
n045
(2045)
(G121)
Connector display, decimal [SW 2.0 and later]
Decimal display with sign of the values of the connectors selected with
U044. In the case of double-word connectors the H word is displayed.
i001: Display of the connector selected with U044.01
i002: Display of the connector selected with U044.02
i003: Display of the connector selected with U044.03
i004: Display of the connector selected with U044.04
i005: Display of the connector selected with U044.05
-32768 to 32767
1
Ind:5
Type: I2
P052 = 3
U046
(2046)
*
(G121)
Connector display, hexadecimal [SW 2.0 and later]
Selection of connectors whose value is to be displayed as a hexadecimal
value with n047l
i001: Selection of the connector to be displayed with n047.01
i002: Selection of the connector to be displayed with n047.02
i003: Selection of the connector to be displayed with n047.03
i004: Selection of the connector to be displayed with n047.04
i005: Selection of the connector to be displayed with n047.05
All connector
numbers
1
Ind: 5
FS=0
Type: L2
P052 = 3
P051 =40
online
n047
(2047)
(G121)
Connector display, hexadecimal [SW 2.0 and later]
Hexadecimal display of values of connectors selected with U046. In the
case of double-word connectors the H word is displayed.
i001: Display of the connector selected with U046.01
i002: Display of the connector selected with U046.02
i003: Display of the connector selected with U046.03
i004: Display of the connector selected with U046.04
i005: Display of the connector selected with U046.05
0000h to FFFFh
1
Ind:5
Type: L2
P052 = 3
