05.05 Parameter list
SIEMENS AG 6RX1700-0AD76 11-101
SIMOREG DC Master Operating Instructions
PNU Description Value range
[Unit]
Steps
No. indices
Factory
setting
Type
See
Change
(Access /
Status)
n014
(2014)
S00
(B121)
Binector/connector converter 2 (bit field 5) FB 14
As for n013
Ind: None
Type: V2
P052 = 3
n015
(2015)
S00
(B121)
Binector/connector converter 3 (bit field 6) FB 15
As for n013
Ind: None
Type: V2
P052 = 3
Technology controller
n016
(2016)
S00
(B170)
Actual value display FB 260
-200.0 to 199.9
[%]
0.1
Ind: None
Type: I2
P052 = 3
n017
(2017)
S00
(B170)
Setpoint display FB 260
-200.0 to 199.9
[%]
0.1
Ind: None
Type: I2
P052 = 3
n018
(2018)
S00
(B170)
Display of effective Kp factor FB 260
0.00 to 30.00
0.01
Ind: None
Type: O2
P052 = 3
n019
(2019)
S00
(B170)
Display of technology controller output FB 260
-200.0 to 199.9
[%]
0.1
Ind: None
Type: I2
P052 = 3
Velocity/speed calculator
n020
(2020)
S00
(B190)
Display of actual speed FB 261
-200.0 to 199.9
[%]
0.1
Ind: None
Type: I2
P052 = 3
n021
(2021)
S00
(B190)
Display of actual velocity FB 261
-32.768 to 32767
[m/s]
0.001
Ind: None
Type: I2
P052 = 3
n022
(2022)
S00
(B190)
Display of setpoint velocity FB 261
-32.768 to 32767
[m/s]
0.001
Ind: None
Type: I2
P052 = 3
n023
(2023)
S00
(B190)
Display of setpoint speed FB 261
-200.0 to 199.9
[%]
0.1
Ind: None
Type: I2
P052 = 3
11.55 Miscellaneous
n024
(2024)
(G145)
(Z120)
Display of the speed actual value in rpm [SW 2.0 and later]
i001: Display of the speed actual value from the pulse generator input
of basic device X173
i002: Display of speed actual value from tacho module SBP
-32768 to 32767
[rpm]
1
Ind: 2
Type: I2
P052 = 2
U040
to
U041
Reserved for later use [SW 2.0 and later]
These parameters must not
be changed by the user!
P052 = 3
