Parameter list 05.05
11-104 SIEMENS AG 6RX1700-0AD76
SIMOREG DC Master Operating Instructions
PNU Description Value range
[Unit]
Steps
No. indices
Factory
setting
Type
See
Change
(Access /
Status)
U101
(2101)
*
S00
(B115)
Source for the activation of F024 and F020 FB 3, FB 287
Selection of the binectors that activate fault messages F024 or F020 on
log. "1"
0 = Binector B0000
1 = Binector B0001
etc.
Up to SW 1.7: F024 (without fault value) if binector = 1 (FB 3)
SW 1.8 and later:
i001: F024 with fault value 1 (FB 3)
i002: F024 with fault value 2
i003: F024 with fault value 3
i004: F024 with fault value 4
i005: F020 with fault value 1 (FB 287)
i006: F020 with fault value 2
i007: F020 with fault value 3
i008: F020 with fault value 4
All binector numbers
1
Ind: 8
FS=0
Type: L2
P052 = 3
P051 = 40
off-line
U102
(2102)
*
S00
(B115)
Source for the activation of F033 and F053 FB 4, FB 288
Selection of the binectors that activate fault messages F033 or F053 on
log. "1"
0 = Binector B0000
1 = Binector B0001
etc.
Up to SW 1.7: F033 (without fault value) if binector = 1 (FB 4)
SW 1.8 and later:
i001: F033 with fault value 1 (FB 4)
i002: F033 with fault value 2
i003: F033 with fault value 3
i004: F033 with fault value 4
i005: F053 with fault value 1 (FB 288)
i006: F053 with fault value 2
i007: F053 with fault value 3
i008: F053 with fault value 4
All binector numbers
1
Ind: 8
FS=0
Type: L2
P052 = 3
P051 = 40
off-line
U103
(2103)
*
S00
(B115)
Source for the activation of F034 and F054 FB 5, FB 289
Selection of the binectors that activate fault messages F034 or F054 on log.
"1"
0 = Binector B0000
1 = Binector B0001
etc.
Up to SW 1.7: F034 (without Fault value) if binector = 1 (FB 5)
SW 1.8 and later:
i001: F034 with fault value 1 (FB 5)
i002: F034 with fault value 2
i003: F034 with fault value 3
i004: F034 with fault value 4
i005: F054 with fault value 1 (FB 289)
i006: F054 with fault value 2
i007: F054 with fault value 3
i008: F054 with fault value 4
All binector numbers
1
Ind: 8
FS=0
Type: L2
P052 = 3
P051 = 40
off-line
U104
(2104)
*
S00
(B115)
Source for the activation of A023 and A019 FB 6, FB 256
Selection of the binectors that activate alarm A023 or A019 on log. "1"
0 = Binector B0000
1 = Binector B0001
etc.
Up to SW 1.7: A023 (FB 6)
SW 1.8 and later:
i001: A023 (FB 6)
i002: A019 (FB 256)
All binector numbers
1
Ind: 2
FS=0
Type: L2
P052 = 3
P051 = 40
off-line
