05.05 Parameter list
SIEMENS AG 6RX1700-0AD76 11-105
SIMOREG DC Master Operating Instructions
PNU
Description Value range
[Unit]
Steps
No. indices
Factory
setting
Type
See
Change
(Access /
Status)
U105
(2105)
*
S00
(B115)
Source for the activation of A024 and A020 FB 7, FB 257
Selection of the binectors that activate alarm A024 or A020 on log. "1"
0 = Binector B0000
1 = Binector B0001
etc.
Up to SW 1.7: A024 (FB 7)
SW 1.8 and later:
i001: A024 (FB 7)
i002: A020 (FB 257)
All binector numbers
1
Ind: 2
FS=0
Type: L2
P052 = 3
P051 = 40
off-line
U106
(2106)
*
S00
(B115)
Source for the activation of A033 and A053 FB 8, FB 258
Selection of the binectors that activate alarm A033 or A053 on log. "1"
0 = Binector B0000
1 = Binector B0001
etc.
Up to SW 1.7: A033 (FB 8)
SW 1.8 and later:
i001: A033 (FB 8)
i002: A053 (FB 258)
All binector numbers
1
Ind: 2
FS=0
Type: L2
P052 = 3
P051 = 40
off-line
U107
(2107)
*
S00
(B115)
Source for the activation of A034 and A054 FB 9, FB 259
Selection of the binectors that activate alarm A034 or A054 on log. "1"
0 = Binector B0000
1 = Binector B0001
etc.
Up to SW 1.7: A034 (FB 9)
SW 1.8 and later:
i001: A034 (FB 9)
i002: A054 (FB 259)
All binector numbers
1
Ind: 2
FS=0
Type: L2
P052 = 3
P051 = 40
off-line
11.58 Connector/binector converters, binector/connector converters
Only active with optional technology software S00
U110
(2110)
*
S00
(B120)
Source for connector/binector converter 1 FB 10
Connector which must be converted to binectors B9052 (bit 0) to B9067 (bit
15)
0 = connector K0000
1 = connector K0001
etc.
All connector
numbers
1
Ind: None
FS=0
Type: L2
P052 = 3
P051 = 40
Offline
U111
(2111)
*
S00
(B120)
Source for connector/binector converter 2 FB 11
Connector which must be converted to binectors B9068 (bit 0) to B9083 (bit
15)
0 = connector K0000
1 = connector K0001
etc.
All connector
numbers
1
Ind: None
FS=0
Type: L2
P052 = 3
P051 = 40
Offline
U112
(2112)
*
S00
(B120)
Source for connector/binector converter 3 FB 12
Connector which must be converted to binectors B9084 (bit 0) to B9099 (bit
15)
0 = connector K0000
1 = connector K0001
etc.
All connector
numbers
1
Ind: None
FS=0
Type: L2
P052 = 3
P051 = 40
Offline
