Siemens 6RA7086-6KS22

Parameter list 05.05
11-106 SIEMENS AG 6RX1700-0AD76
SIMOREG DC Master Operating Instructions
PNU Description Value range
[Unit]
Steps
No. indices
Factory
setting
Type
See
Change
(Access /
Status)
U113
(2113)
*
S00
(B121)
Source for binector/connector converter 1 FB 13
Binectors which must be converted to connector K9113
i001: 1
st
binector (bit 0)
i002: 2
nd
binector (bit 1)
...
i016: 16
th
binector (bit 15)
Settings:
0 = binector B0000
1 = binector B0001
etc.
All binector numbers
1
Ind: 16
FS=0
Type: L2
P052 = 3
P051 = 40
Offline
U114
(2114)
*
S00
(B121)
Source for binector/connector converter 2 FB 14
Binectors which must be converted to connector K9114
i001: 1
st
binector (bit 0)
i002: 2
nd
binector (bit 1)
...
i016: 16
th
binector (bit 15)
Settings:
0 = binector B0000
1 = binector B0001
etc.
All binector numbers
1
Ind: 16
FS=0
Type: L2
P052 = 3
P051 = 40
Offline
U115
(2115)
*
S00
(B121)
Source for binector/connector converter 3 FB 15
Binectors which must be converted to connector K9115
i001: 1
st
binector (bit 0)
i002: 2
nd
binector (bit 1)
...
i016: 16
th
binector (bit 15)
Settings:
0 = binector B0000
1 = binector B0001
etc.
All binector numbers
1
Ind: 16
FS=0
Type: L2
P052 = 3
P051 = 40
Offline
11.59 Binector/connector converter for serial interfaces
U116
(2116)
*
(G170)
Source for binector/connector converter for GSST1 [SW1.4 and later]
Binectors which must be converted to connector K2020
i001: 1
st
binector (bit 0)
i002: 2
nd
binector (bit 1)
...
i016: 16
th
binector (bit 15)
Settings:
0 = binector B0000
1 = binector B0001
etc.
All binector numbers
1
Ind: 16
FS=0
Type: L2
P052 = 3
P051 = 40
Offline
U117
(2117)
*
(G171)
(G173)
Source for binector/connector converter for GSST2 [SW1.4 and later]
Binectors which must be converted to connector K6020
i001: 1
st
binector (bit 0)
i002: 2
nd
binector (bit 1)
...
i016: 16
th
binector (bit 15)
Settings:
0 = binector B0000
1 = binector B0001
etc.
All binector numbers
1
Ind: 16
FS=0
Type: L2
P052 = 3
P051 = 40
Offline
