Siemens 6RA7086-6KS22

05.05 Parameter list
SIEMENS AG 6RX1700-0AD76 11-107
SIMOREG DC Master Operating Instructions
PNU Description Value range
[Unit]
Steps
No. indices
Factory
setting
Type
See
Change
(Access /
Status)
U118
(2118)
*
(G172)
(G174)
Source for binector/connector converter for GSST3 [SW1.4 and later]
Binectors which must be converted to connector K9020
i001: 1
st
binector (bit 0)
i002: 2
nd
binector (bit 1)
...
i016: 16
th
binector (bit 15)
Settings:
0 = binector B0000
1 = binector B0001
etc.
All binector numbers
1
Ind: 16
FS=0
Type: L2
P052 = 3
P051 = 40
Offline
U119
(2119)
*
Parameters for the Trace function of DriveMonitor [SW1.4 and later]
This parameter is a setting for the exchange of process data between
DriveMonitor and the SIMOREG converter. It must not
be changed!
11.60 Mathematical functions
Only active with optional technology software S00
Adder / subtractor
The 3 operands of a function block are selected by 3 indices each of a parameter.
U120 to U131:
The connectors selected via indices i001 and i002 are added, the connector selected via index i003 is subtracted.
U120 to U122 [SW 1.8 and later]:
The connectors selected via indices i004 and i005 are added, the connector selected via index i006 is subtracted.
The result is limited to -200.00 to +199.99% and applied to the connector stated.
U120
(2120)
*
S00
(B125)
Operands for 1st adder / subtractor (result = K9120) FB 20
Operands for 13th adder / subtractor (result = K9132) FB 32
(SW 1.8 and later)
0 = Connector K0000
1 = Connector K0001
etc.
All connector
numbers
1
Ind: 6
FS=0
Type: L2
P052 = 3
P051 = 40
off-line
U121
(2121)
*
S00
(B125)
Operands for 2nd adder / subtractor (result = K9121) FB 21
Operands for 14th adder / subtractor (result = K9133) FB 33
[SW 1.8 and later]
0 = Connector K0000
1 = Connector K0001
etc.
All connector
numbers
1
Ind: 6
FS=0
Type: L2
P052 = 3
P051 = 40
off-line
U122
(2122)
*
S00
(B125)
Operands for 3rd adder / subtractor (result = K9122) FB 22
Operands for 14th adder / subtractor (result = K9134) FB 34
[SW 1.8 and later]
0 = Connector K0000
1 = Connector K0001
etc.
All connector
numbers
1
Ind: 6
FS=0
Type: L2
P052 = 3
P051 = 40
off-line
U123
(2123)
*
S00
(B125)
Operands for 4
th
adder / subtracter (result = K9123) FB 23
0 = connector K0000
1 = connector K0001
etc.
All connector
numbers
1
Ind: 3
FS=0
Type: L2
P052 = 3
P051 = 40
Offline
U124
(2124)
*
S00
(B125)
Operands for 5
th
adder / subtracter (result = K9124) FB 24
0 = connector K0000
1 = connector K0001
etc.
All connector
numbers
1
Ind: 3
FS=0
Type: L2
P052 = 3
P051 = 40
Offline
U125
(2125)
*
S00
(B125)
Operands for 6
th
adder / subtracter (result = K9125) FB 25
0 = connector K0000
1 = connector K0001
etc.
All connector
numbers
1
Ind: 3
FS=0
Type: L2
P052 = 3
P051 = 40
Offline
