SIMOREG DC Master Operating Instructions
PNU Description Value range
[Unit]
Steps
No. indices
Factory
setting
Type
See
Change
(Access /
Status)
Limit-value monitors with filtering
U185
(2185)
*
S00
(B136)
Source for input signal (A) and operating point (B) for FB 70
1
st
limit-value monitor with filtering
i001: Input signal
i002: Operating point
Settings:
0 = connector K0000
1 = connector K0001
etc.
All connector
numbers
1
Ind: 2
FS=
i001: 0
i002: 9181
Type: L2
P052 = 3
P051 = 40
Offline
U186
(2186)
S00
(B136)
Settable operating point for limit-value monitor FB 70
Applied to connector K9181
-200.00 to 199.99
[%]
0.01%
Ind: None
FS=0.00
Type: I2
P052 = 3
P051 = 40
Offline
U187
(2187)
S00
(B136)
Filter time for 1
st
limit-value monitor with filtering FB 70
0 to 10000
[ms]
1
Ind: None
FS=0
Type: O2
P052 = 3
P051 = 40
Offline
U188
(2188)
S00
(B136)
Hysteresis for 1
st
limit-value monitor with filtering FB 70
0.00 to 100.00
[%]
0.01%
Ind: None
FS=0.00
Type: O2
P052 = 3
P051 = 40
Offline
U189
(2189)
*
S00
(B136)
Source for input signal (A) and operating point (B) for FB 71
2
nd
limit-value monitor with filtering
i001: Input signal
i002: Operating point
Settings:
0 = connector K0000
1 = connector K0001
etc.
All connector
numbers
1
Ind: 2
FS=
i001: 0
i002: 9183
Type: L2
P052 = 3
P051 = 40
Offline
U190
(2190)
S00
(B136)
Settable operating point for limit-value monitor FB 71
Applied to connector K9183
-200.00 to 199.99
[%]
0.01%
Ind: None
FS=0.00
Type: I2
P052 = 3
P051 = 40
Offline
U191
(2191)
S00
(B136)
Filter time for 2
nd
limit-value monitor with filtering FB 71
0 to 10000
[ms]
1
Ind: None
FS=0
Type: O2
P052 = 3
P051 = 40
Offline
U192
(2192)
S00
(B136)
Hysteresis for 2
nd
limit-value monitor with filtering FB 71
0.00 to 100.00
[%]
0.01%
Ind: None
FS=0.00
Type: O2
P052 = 3
P051 = 40
Offline
U193
(2193)
*
S00
(B136)
Source for input signal (A) and operating point (B) for FB 72
3
rd
limit-value monitor with filtering
i001: Input signal
i002: Operating point
Settings:
0 = connector K0000
1 = connector K0001
etc.
All connector
numbers
1
Ind: 2
FS=
i001: 0
i002: 9185
Type: L2
P052 = 3
P051 = 40
Offline
U194
(2194)
S00
(B136)
Settable operating point for limit-value monitor FB 72
Applied to connector K9185
-200.00 to 199.99
[%]
0.01%
Ind: None
FS=0.00
Type: I2
P052 = 3
P051 = 40
Offline
U195
(2195)
S00
(B136)
Filter time for 3
rd
limit-value monitor with filtering FB 72
0 to 10000
[ms]
1
Ind: None
FS=0
Type: O2
P052 = 3
P051 = 40
Offline
U196
(2196)
S00
(B136)
Hysteresis for 3
rd
limit-value monitor with filtering FB 72
0.00 to 100.00
[%]
0.01%
Ind: None
FS=0.00
Type: O2
P052 = 3
P051 = 40
Offline
