05.05 Parameter list
SIEMENS AG 6RX1700-0AD76 11-113
SIMOREG DC Master Operating Instructions
PNU Description Value range
[Unit]
Steps
No. indices
Factory
setting
Type
See
Change
(Access /
Status)
U177
(2177)
*
S00
(B134)
(B135)
Source for input signal and limits for limiter 2 FB 66
Output = connector K9170
i001: Input signal
i002: Upper limiting value (L+)
i003: Lower limiting value (L-)
Source for input signal and limits for limiter 5 FB 213
[SW2.0 and later]
Output = connector K9179
i004: Input signal
i005: Upper limiting value (L+)
i006: Lower limiting value (L-)
Settings:
0 = connector K0000
1 = connector K0001
etc.
All connector
numbers
1
Ind: 6
FS=
i001: 0
i002: 9168
i003: 9169
i004: 0
i005: 9177
i006: 9178
Type: L2
P052 = 3
P051 = 40
Offline
U178
(2178)
S00
(B134)
(B135)
Limit value for limiter FB 66, FB213
i001: Applied to connector K9168 (FB 66)
i002: Applied to connector K9177 (FB 213) [SW2.0 and later]
-199.99 to 199.99
[%]
0.01%
Ind: 2
FS=100.00
Type: I2
P052 = 3
P051 = 40
Offline
U179
(2179)
*
S00
(B134)
(B135)
Source for input signal and limits for limiter 3 FB 67
Output = connector K9173
i001: Input signal
i002: Upper limiting value (L+)
i003: Lower limiting value (L-)
Source for input signal and limits for limiter 6 FB 214
[SW2.0 and later]
Output = connector K9262
i004: Input signal
i005: Upper limiting value (L+)
i006: Lower limiting value (L-)
Settings:
0 = connector K0000
1 = connector K0001
etc.
All connector
numbers
1
Ind: 6
FS=
i001: 0
i002: 9171
i003: 9172
i004: 0
i005: 9260
i006: 9261
Type: L2
P052 = 3
P051 = 40
Offline
U180
(2180)
S00
(B134)
(B135)
Limit value for limiter FB 67, FB214
i001: Applied to connector K9171 (FB 67)
i002: Applied to connector K9260 (FB 214) [SW2.0 and later]
-199.99 to 199.99
[%]
0.01%
Ind: 2
FS=100.00
Type: I2
P052 = 3
P051 = 40
Offline
Limit-value monitors for double word connectors
U181
(2181)
*
S00
(B151)
Source for input signal (A) and operating threshold (B)
for 1
st
limit-value monitor for double word connectors FB 68
for 2
nd
limit-value monitor for double word connectors FB 69
[SW 1.9 and later]
i001: Input signal for 1
st
limit-value monitor
i002: Operating threshold for 1
st
limit-value monitor
i003: Input signal for 2
nd
limit-value monitor
i004: Operating threshold for 2
nd
limit-value monitor
Settings:
0 = connector K0000
1 = connector K0001
etc.
All connector
numbers
1
Ind: 4
FS=0
Type: L2
P052 = 3
P051 = 40
off-line
U182
(2182)
S00
(B151)
Hysteresis for 1
st
limit-value monitor for double word connectors FB 68
Hysteresis for 2
nd
limit-value monitor for double word connectors FB69
[SW 1.9 and later]
i001: Hysteresis for 1
st
limit-value monitor
i002: Hysteresis for 2
nd
limit-value monitor
0.00 to 100.00
[%]
0.01%
Ind: 2
FS=0.00
Type: O2
P052 = 3
P051 = 40
off-line
