Siemens 6RA7086-6KS22

Parameter list 05.05
11-112 SIEMENS AG 6RX1700-0AD76
SIMOREG DC Master Operating Instructions
PNU Description Value range
[Unit]
Steps
No. indices
Factory
setting
Type
See
Change
(Access /
Status)
11.61 Processing of connectors
Only active with optional technology software S00
Averager [SW 1.8 and later]
U172
(2172)
*
S00
(B139)
Source for input signal [SW 1.8 and later]
i001: 1st averager (FB 16)
i002: 2nd averager (FB 17)
i003: 3rd averager (FB 18)
i004: 4. averager (FB 19)
Settings:
0 = Connector K0000
1 = Connector K0001
etc.
All connector
numbers
1
Ind: 4
FS=0
Type: L2
P052 = 3
P051 = 40
off-line
U173
(2173)
S00
(B139)
Number of sampling cycles [SW 1.8 and later]
i001: 1st averager (FB 16)
i002: 2nd averager (FB 17)
i003: 3rd averager (FB 18)
i004: 4. averager (FB 19)
1 to 100
1
Ind: 4
FS=1
Type: O2
P052 = 3
P051 = 40
on-line
11.62 Limiters, limit-value monitors
Only active with optional technology software S00
Limiters
The input variable selected with index i001 or i004 of the 1
st
parameter is limited to the limit values selected with indices i002 and i003 or
i005 and i006 and applied to the specified connector. Violation of the limit values is signaled by means of two binectors.
U175
(2175)
*
S00
(B134)
(B135)
Source for input signal and limits for limiter 1 FB 65
Output = connector K9167
i001: Input signal
i002: Upper limiting value (L+)
i003: Lower limiting value (L-)
Source for input signal and limits for limiter 4 FB 212
[SW2.0 and later]
Output = connector K9176
i004: Input signal
i005: Upper limiting value (L+)
i006: Lower limiting value (L-)
Settings:
0 = connector K0000
1 = connector K0001
etc.
All connector
numbers
1
Ind: 6
FS=
i001: 0
i002: 9165
i003: 9166
i004: 0
i005: 9174
i006: 9175
Type: L2
P052 = 3
P051 = 40
Offline
U176
(2176)
S00
(B134)
(B135)
Limit value for limiter FB 65, FB212
i001: Applied to connector K9165 (FB 65)
i002: Applied to connector K9174 (FB 212) [SW2.0 and later]
-199.99 to 199.99
[%]
0.01%
Ind: 2
FS=100.00
Type: I2
P052 = 3
P051 = 40
Offline
