Siemens 6RA7086-6KS22

05.05 Parameter list
SIEMENS AG 6RX1700-0AD76 11-111
SIMOREG DC Master Operating Instructions
PNU Description Value range
[Unit]
Steps
No. indices
Factory
setting
Type
See
Change
(Access /
Status)
U161
(2161)
*
S00
(B135)
Signal injection mode for 1
st
abs.-value generator with filter FB 60
0 Injection of signal with correct sign
1 Injection of absolute value of signal
2 Injection of signal with sign, inverted
3 Injection of absolute value of signal, inverted
0 to 3
1
Ind: None
FS=0
Type: O2
P052 = 3
P051 = 40
Offline
U162
(2162)
S00
(B135)
Filter time for 1
st
abs.-value generator with filter FB 60
0 to 10000
[ms]
1
Ind: None
FS=0
Type: O2
P052 = 3
P051 = 40
Offline
U163
(2163)
*
S00
(B135)
Source for input quantity for 2
nd
abs.-value generator with filter FB 61
0 = connector K0000
1 = connector K0001
etc.
All connector
numbers
1
Ind: None
FS=0
Type: L2
P052 = 3
P051 = 40
Offline
U164
(2164)
*
S00
(B135)
Signal injection mode for 2
nd
abs.-value generator with filter FB 61
0 Injection of signal with correct sign
1 Injection of absolute value of signal
2 Injection of signal with sign, inverted
3 Injection of absolute value of signal, inverted
0 to 3
1
Ind: None
FS=0
Type: O2
P052 = 3
P051 = 40
Offline
U165
(2165)
S00
(B135)
Filter time for 2
nd
abs.-value generator with filter FB 61
0 to 10000
[ms]
1
Ind: None
FS=0
Type: O2
P052 = 3
P051 = 40
Offline
U166
(2166)
*
S00
(B135)
Source for input quantity for 3
rd
abs.-value generator with filter FB 62
0 = connector K0000
1 = connector K0001
etc.
All connector
numbers
1
Ind: None
FS=0
Type: L2
P052 = 3
P051 = 40
Offline
U167
(2167)
*
S00
(B135)
Signal injection mode for 3
rd
abs.-value generator with filter FB 62
0 Injection of signal with correct sign
1 Injection of absolute value of signal
2 Injection of signal with sign, inverted
3 Injection of absolute value of signal, inverted
0 to 3
1
Ind: None
FS=0
Type: O2
P052 = 3
P051 = 40
Offline
U168
(2168)
S00
(B135)
Filter time for 3
rd
abs.-value generator with filter FB 62
0 to 10000
[ms]
1
Ind: None
FS=0
Type: O2
P052 = 3
P051 = 40
Offline
U169
(2169)
*
S00
(B135)
Source for input quantity for 4
th
abs.-value generator with filter FB 63
0 = connector K0000
1 = connector K0001
etc.
All connector
numbers
1
Ind: None
FS=0
Type: L2
P052 = 3
P051 = 40
Offline
U170
(2170)
*
S00
(B135)
Signal injection mode for 4
th
abs.-value generator with filter FB 63
0 Injection of signal with correct sign
1 Injection of absolute value of signal
2 Injection of signal with sign, inverted
3 Injection of absolute value of signal, inverted
0 to 3
1
Ind: None
FS=0
Type: O2
P052 = 3
P051 = 40
Offline
U171
(2171)
S00
(B135)
Filter time for 4
th
abs.-value generator with filter FB 63
0 to 10000
[ms]
1
Ind: None
FS=0
Type: O2
P052 = 3
P051 = 40
Offline
