Parameter list 05.05
11-110 SIEMENS AG 6RX1700-0AD76
SIMOREG DC Master Operating Instructions
PNU
Description Value range
[Unit]
Steps
No. indices
Factory
setting
Type
See
Change
(Access /
Status)
Multiplier
The two operands (x1, x2) for each multiplier are selected via 2 indices of the parameter each:
Index i001 = x1, Index i002 = x2
Index i003 = x1, Index i004 = x2 [SW 1.8 and later]
Index i005 = x1, Index i006 = x2 [SW 1.8 and later]
Formula:
y
xx
=
∗12
100%
y is limited to -200.00 to +199.99% and applied to the connector stated.
U150
(2150)
*
S00
(B130)
Operands for 1st multiplier (result = K9150) FB 50
Operands for 5th multiplier (result = K9430) FB 290
Operands for 9th multiplier (result = K9431) FB 291
0 = Connector K0000
1 = Connector K0001
etc.
All connector
numbers
1
Ind: 6
FS=0
Type: L2
P052 = 3
P051 = 40
off-line
U151
(2151)
*
S00
(B130)
Operands for 2nd multiplier (result = K9151) FB 51
Operands for 6th multiplier (result = K9432) FB 292
Operands for 10th multiplier (result = K9433) FB 293
0 = Connector K0000
1 = Connector K0001
etc.
All connector
numbers
1
Ind: 6
FS=0
Type: L2
P052 = 3
P051 = 40
off-line
U152
(2152)
*
S00
(B130)
Operands for 3rd multiplier (result = K9152) FB 52
Operands for 7thmultiplier (result = K9434) FB 294
Operands for 11th multiplier (result = K9435) FB 295
0 = Connector K0000
1 = Connector K0001
etc.
All connector
numbers
1
Ind: 6
FS=0
Type: L2
P052 = 3
P051 = 40
off-line
U153
(2153)
*
S00
(B130)
Operands for 4th multiplier (result = K9153) FB 53
Operands for 8the multiplier (result = K9436) FB 296
Operands for 12th multiplier (result = K9437) FB 297
0 = Connector K0000
1 = Connector K0001
etc.
All connector
numbers
1
Ind: 6
FS=0
Type: L2
P052 = 3
P051 = 40
off-line
High-resolution multipliers/dividers
The three operands are selected via the three indices of the parameter, i.e. index i001 = x1, index i002 = x2, index i003 = x3
Equations:
xbitxx432 1 2()=∗ , y
x
x
xx
x
==
∗
4
3
12
3
Applicable for division by 0 (x2=0):
When x1 > 0: y = +199.99%
When x1 = 0: y = 0.00%
When x1 < 0: y = -200.00%
y is limited to -200.00 to +199.99% and applied to the specified connector.
U155
(2155)
*
S00
(B131)
Operands for 1
st
multiplier/divider (result = K9155) FB 55
0 = connector K0000
1 = connector K0001
etc.
All connector
numbers
1
Ind: 3
FS=1
Type: L2
P052 = 3
P051 = 40
Offline
U156
(2156)
*
S00
(B131)
Operands for 2
nd
multiplier/divider (result = K9156) FB 56
0 = connector K0000
1 = connector K0001
etc.
All connector
numbers
1
Ind: 3
FS=1
Type: L2
P052 = 3
P051 = 40
Offline
U157
(2157)
*
S00
(B131)
Operands for 3
rd
multiplier/divider (result = K9157) FB 57
0 = connector K0000
1 = connector K0001
etc.
All connector
numbers
1
Ind: 3
FS=1
Type: L2
P052 = 3
P051 = 40
Offline
Absolute-value generators with filtering
U160
(2160)
*
S00
(B135)
Source for input quantity for 1
st
abs.-value generator with filter FB 60
0 = connector K0000
1 = connector K0001
etc.
All connector
numbers
1
Ind: None
FS=0
Type: L2
P052 = 3
P051 = 40
Offline
