05.05 Parameter list
SIEMENS AG 6RX1700-0AD76 11-109
SIMOREG DC Master Operating Instructions
PNU Description Value range
[Unit]
Steps
No. indices
Factory
setting
Type
See
Change
(Access /
Status)
U138
(2138)
*
S00
(B125)
Source for 4
th
sign inverter (result = K9138) FB 38
0 = connector K0000
1 = connector K0001
etc.
All connector
numbers
1
Ind: None
FS=0
Type: L2
P052 = 3
P051 = 40
Offline
Switchable sign inverters
The contents of the connector entered in the parameter for selection of a source is switched through, depending on the state of the
binector entered in the parameter for control bit selection, as an unchanged value (when control bit = 0) or as a negated value (two's
complement, when control bit = 1). The result is applied to the specified connector.
U140
(2140)
*
S00
(B125)
Source for 1
st
switchable sign inverter FB 40
Result = K9140
0 = connector K0000
1 = connector K0001
etc.
All connector
numbers
1
Ind: None
FS=0
Type: L2
P052 = 3
P051 = 40
Offline
U141
(2141)
*
S00
(B125)
Control bit for 1
st
switchable sign inverter FB 40
0 = binector B0000
1 = binector B0001
etc.
All binector numbers
1
Ind: None
FS=0
Type: L2
P052 = 3
P051 = 40
Offline
U142
(2142)
*
S00
(B125)
Source for 2
nd
switchable sign inverter FB 41
Result = K9141
0 = connector K0000
1 = connector K0001
etc.
All connector
numbers
1
Ind: None
FS=0
Type: L2
P052 = 3
P051 = 40
Offline
U143
(2143)
*
S00
(B125)
Control bit for 2
nd
switchable sign inverter FB 41
0 = binector B0000
1 = binector B0001
etc.
All binector numbers
1
Ind: None
FS=0
Type: L2
P052 = 3
P051 = 40
Offline
Divider
The two operands (x1, x2) for each divider are selected via 2 indices each of the parameter:
Index i001 = x1, index i002 = x2
Index i003 = x1, index i004 = x2 [SW 1.8 and later]
Formula:
y
x
x
=
∗1 100%
2
For division by 0 (x2=0) the following applies:
for x1 > 0: y = +199.99%
for x1 = 0: y = 0.00%
for x1 < 0: y = -200.00%
y is limited to -200.00 to +199.99% and applied to the connector stated.
U145
(2145)
*
S00
(B131)
Operands for 1st divider (result = K9145) FB 45
Operands for 4th divider (result = K9142) FB 42
0 = Connector K0000
1 = Connector K0001
etc.
All connector
numbers
1
Ind: 4
FS=1
Type: L2
P052 = 3
P051 = 40
off-line
U146
(2146)
*
S00
(B131)
Operands for 2nd divider (result = K9146) FB 46
Operands for 5th divider (result = K9143) FB 43
0 = Connector K0000
1 = Connector K0001
etc.
All connector
numbers
1
Ind: 4
FS=1
Type: L2
P052 = 3
P051 = 40
off-line
U147
(2147)
*
S00
(B131)
Operands for 3rd divider (result = K9147) FB 47
Operands for 6th divider (result = K9144) FB 44
0 = Connector K0000
1 = Connector K0001
etc.
All connector
numbers
1
Ind: 4
FS=1
Type: L2
P052 = 3
P051 = 40
off-line
