Siemens 6RA7086-6KS22

Parameter list 05.05
11-116 SIEMENS AG 6RX1700-0AD76
SIMOREG DC Master Operating Instructions
PNU Description Value range
[Unit]
Steps
No. indices
Factory
setting
Type
See
Change
(Access /
Status)
U208
(2208)
S00
(B137)
Hysteresis for 4
th
limit-value monitor without filtering FB 76
0.00 to 100.00
[%]
0.01%
Ind: None
FS=0.00
Type: O2
P052 = 3
P051 = 40
Offline
U210
(2210)
*
S00
(B138)
Source for input signal (A) and operating point (B) for FB 77
5
th
limit-value monitor without filtering
i001: Input signal
i002: Operating point
Settings:
0 = connector K0000
1 = connector K0001
etc.
All connector
numbers
1
Ind: 2
FS=
i001: 0
i002: 9190
Type: L2
P052 = 3
P051 = 40
Offline
U211
(2211)
S00
(B138)
Settable operating point for limit-value monitor FB 77
Applied to connector K9190
-200.00 to 199.99
[%]
0.01%
Ind: None
FS=0.00
Type: I2
P052 = 3
P051 = 40
Offline
U212
(2212)
S00
(B138)
Hysteresis for 5
th
limit-value monitor without filtering FB 77
0.00 to 100.00
[%]
0.01%
Ind: None
FS=0.00
Type: O2
P052 = 3
P051 = 40
Offline
U213
(2213)
*
S00
(B138)
Source for input signal (A) and operating point (B) for FB 78
6
th
limit-value monitor without filtering
i001: Input signal
i002: Operating point
Settings:
0 = connector K0000
1 = connector K0001
etc.
All connector
numbers
1
Ind: 2
FS=
i001: 0
i002: 9191
Type: L2
P052 = 3
P051 = 40
Offline
U214
(2214)
S00
(B138)
Settable operating point for limit-value monitor FB 78
Applied to connector K9191
-200.00 to 199.99
[%]
0.01%
Ind: None
FS=0.00
Type: I2
P052 = 3
P051 = 40
Offline
U215
(2215)
S00
(B138)
Hysteresis for 6
th
limit-value monitor without filtering FB 78
0.00 to 100.00
[%]
0.01%
Ind: None
FS=0.00
Type: O2
P052 = 3
P051 = 40
Offline
U216
(2216)
*
S00
(B138)
Source for input signal (A) and operating point (B) for FB 79
7
th
limit-value monitor without filtering
i001: Input signal
i002: Operating point
Settings:
0 = connector K0000
1 = connector K0001
etc.
All connector
numbers
1
Ind: 2
FS=
i001: 0
i002: 9192
Type: L2
P052 = 3
P051 = 40
Offline
U217
(2217)
S00
(B138)
Settable operating point for limit-value monitor FB 79
Applied to connector K9192
-200.00 to 199.99
[%]
0.01%
Ind: None
FS=0.00
Type: I2
P052 = 3
P051 = 40
Offline
U218
(2218)
S00
(B138)
Hysteresis for 7
th
limit-value monitor without filtering FB 79
0.00 to 100.00
[%]
0.01%
Ind: None
FS=0.00
Type: O2
P052 = 3
P051 = 40
Offline
