05.05 Parameter list
SIEMENS AG 6RX1700-0AD76 11-117
SIMOREG DC Master Operating Instructions
PNU Description Value range
[Unit]
Steps
No. indices
Factory
setting
Type
See
Change
(Access /
Status)
11.63 Processing of connectors
Only active with optional technology software S00
Maximum selection FB 80, FB 174, FB 175, FB 176
The largest of the input values selected by 3 indices each of the parameter (x1, x2, x3) is applied to the output.
U220
(2220)
*
S00
(B140)
Source for maximum selection
0 = Connector K0000
1 = Connector K0001
etc.
i001: x1 Maximum selection 1 (FB 80, Output = K9193)
i002: x2 Maximum selection 1
i003: x3 Maximum selection 1
SW 1.8 and later:
i004: x1 Maximum selection 2 (FB 174, Output = K9460)
i005: x2 Maximum selection 2
i006: x3 Maximum selection 2
i007: x1 Maximum selection 3 (FB 175, Output = K9461)
i008: x2 Maximum selection 3
i009: x3 Maximum selection 3
i010: x1 Maximum selection 4 (FB 176, Output = K9462)
i011: x2 Maximum selection 4
i012: x3 Maximum selection 4
All connector
numbers
1
Ind: 12
FS=0
Type: L2
P052 = 3
P051 = 40
off-line
Minimum selection FB 81, FB 177, FB 178, FB 179
The smallest of the input values selected by 3 indices each of the parameter (x1, x2, x3) is applied to the output.
U221
(2221)
*
S00
(B140)
Source for minimum selection
0 = Connector K0000
1 = Connector K0001
etc.
i001: x1 Minimum selection 1 (FB 81, Output = K9194)
i002: x2 Minimum selection 1
i003: x3 Minimum selection 1
SW 1.8 and later:
i004: x1 Minimum selection 2 (FB 177, Output = K9463)
i005: x2 Minimum selection 2
i006: x3 Minimum selection 2
i007: x1 Minimum selection 3 (FB 178, Output = K9464)
i008: x2 Minimum selection 3
i009: x3 Minimum selection 3
i010: x1 Minimum selection 4 (FB 179, Output = K9465)
i011: x2 Minimum selection 4
i012: x3 Minimum selection 4
All connector
numbers
1
Ind: 12
FS=0
Type: L2
P052 = 3
P051 = 40
off-line
Tracking/storage elements
The tracking/storage elements are storage elements for the parameterized input quantity. The outputs are linked to connectors.
Transfer of the input quantity is controlled via the RESET, TRACK and STORE functions:
RESET: When the controlling binector reaches log. "1", the output is set to 0.00% (y=0)
TRACK: When the controlling binector reaches log. "1", the output is set to the input value and then tracks it continuously (y=x). If the
TRACK signal switches from "1" to "0", the last value applied to the y output is "frozen"
STORE: With a "0" to "1" transition of the controlling binector signal, the output is permanently set to the current input value (y=x). This
value then remains stored
Priority 1. RESET, 2. TRACK, 3. STORE
Tracking/storage element 1
U222
(2222)
*
S00
(B145)
Source for input quantity (x) FB 82
0 = connector K0000
1 = connector K0001
etc.
All connector
numbers
1
Ind: None
FS=0
Type: L2
P052 = 3
P051 = 40
Offline
