Parameter list 05.05
11-118 SIEMENS AG 6RX1700-0AD76
SIMOREG DC Master Operating Instructions
PNU Description Value range
[Unit]
Steps
No. indices
Factory
setting
Type
See
Change
(Access /
Status)
U223
(2223)
*
S00
(B145)
Source for control signals RESET, TRACK and STORE FB 82
i001: TRACK
i002: STORE
i003: RESET
Settings:
0 = binector B0000
1 = binector B0001
etc.
All binector numbers
1
Ind: 3
FS=0
Type: L2
P052 = 3
P051 = 40
Offline
U224
(2224)
*
S00
(B145)
Control word for Power On Mode FB 82
0 Volatile storage:
Zero appears at output when voltage recovers
1 Non-volatile storage:
When the voltage is disconnected or fails, the current output
value is stored and then output when the voltage recovers/is
reconnected
0 to 1
1
Ind: None
FS=0
Type: O2
P052 = 3
P051 = 40
Offline
Tracking/storage element 2
U225
(2225)
*
S00
(B145)
Source for input quantity (x) FB 83
0 = connector K0000
1 = connector K0001
etc.
All connector
numbers
1
Ind: None
FS=0
Type: L2
P052 = 3
P051 = 40
Offline
U226
(2226)
*
S00
(B145)
Source for control signals RESET, TRACK and STORE FB 83
i001: TRACK
i002: STORE
i003: RESET
Settings:
0 = binector B0000
1 = binector B0001
etc.
All binector numbers
1
Ind: 3
FS=0
Type: L2
P052 = 3
P051 = 40
Offline
U227
(2227)
*
S00
(B145)
Control word for Power On Mode FB 83
0 Volatile storage:
Zero appears at output when voltage recovers
1 Non-volatile storage:
When the voltage is disconnected or fails, the current output
value is stored and then output when the voltage recovers/is
reconnected
0 to 1
1
Ind: None
FS=0
Type: O2
P052 = 3
P051 = 40
Offline
Connector memories
The connector memories are memory elements for the input quantities selected via the parameters. The outputs are linked to connectors.
While the SET input is in the log. "1" state, output quantity y tracks input quantity x continuously. If the SET input changes state from log.
"1" to log. "0", the current value of x is stored and output continuously at y.
Output (y) = 0 is set on POWER ON.
Connector memory 1
U228
(2228)
*
S00
(B145)
Source for input quantity (x) FB 84
0 = connector K0000
1 = connector K0001
etc.
All connector
numbers
1
Ind: None
FS=0
Type: L2
P052 = 3
P051 = 40
Offline
U229
(2229)
*
S00
(B145)
Source for control signal SET FB 84
0 = binector B0000
1 = binector B0001
etc.
All binector numbers
1
Ind: None
FS=0
Type: L2
P052 = 3
P051 = 40
Offline
Connector memory 2
U230
(2230)
*
S00
(B145)
Source for input quantity (x) FB 85
0 = connector K0000
1 = connector K0001
etc.
All connector
numbers
1
Ind: None
FS=0
Type: L2
P052 = 3
P051 = 40
Offline
U231
(2231)
*
S00
(B145)
Source for control signal SET FB 85
0 = binector B0000
1 = binector B0001
etc.
All binector numbers
1
Ind: None
FS=0
Type: L2
P052 = 3
P051 = 40
Offline
