05.05 Parameter list
SIEMENS AG 6RX1700-0AD76 11-119
SIMOREG DC Master Operating Instructions
PNU Description Value range
[Unit]
Steps
No. indices
Factory
setting
Type
See
Change
(Access /
Status)
Connector changeover switches
Depending on the state of the control signal, one of the two input quantities is applied to the output (connector):
Control signal = 0:The input quantity selected in index i001 is applied to the output
Control signal = 1: The input quantity selected in index i002 is applied to the output
Connector changeover switch 1 (output = K9210)
U240
(2240)
*
S00
(B150)
Source for input quantities FB 90
0 = connector K0000
1 = connector K0001
etc.
All connector
numbers
1
Ind: 2
FS=0
Type: L2
P052 = 3
P051 = 40
Offline
U241
(2241)
*
S00
(B150)
Source for control signal FB 90
0 = binector B0000
1 = binector B0001
etc.
All binector numbers
1
Ind: None
FS=0
Type: L2
P052 = 3
P051 = 40
Offline
Connector changeover switch 2 (output = K9211)
U242
(2242)
*
S00
(B150)
Source for input quantities FB 91
0 = connector K0000
1 = connector K0001
etc.
All connector
numbers
1
Ind: 2
FS=0
Type: L2
P052 = 3
P051 = 40
Offline
U243
(2243)
*
S00
(B150)
Source for control signal FB 91
0 = binector B0000
1 = binector B0001
etc.
All binector numbers
1
Ind: None
FS=0
Type: L2
P052 = 3
P051 = 40
Offline
Connector changeover switch 3 (output = K9212)
U244
(2244)
*
S00
(B150)
Source for input quantities FB 92
0 = connector K0000
1 = connector K0001
etc.
All connector
numbers
1
Ind: 2
FS=0
Type: L2
P052 = 3
P051 = 40
Offline
U245
(2245)
*
S00
(B150)
Source for control signal FB 92
0 = binector B0000
1 = binector B0001
etc.
All binector numbers
1
Ind: None
FS=0
Type: L2
P052 = 3
P051 = 40
Offline
Connector changeover switch 4 (output = K9213)
U246
(2246)
*
S00
(B150)
Source for input quantities FB 93
0 = connector K0000
1 = connector K0001
etc.
All connector
numbers
1
Ind: 2
FS=0
Type: L2
P052 = 3
P051 = 40
Offline
U247
(2247)
*
S00
(B150)
Source for control signal FB 93
0 = binector B0000
1 = binector B0001
etc.
All binector numbers
1
Ind: None
FS=0
Type: L2
P052 = 3
P051 = 40
Offline
Connector changeover switch 5 (output = K9214)
U248
(2248)
*
S00
(B150)
Source for input quantities FB 94
0 = connector K0000
1 = connector K0001
etc.
All connector
numbers
1
Ind: 2
FS=0
Type: L2
P052 = 3
P051 = 40
Offline
U249
(2249)
*
S00
(B150)
Source for control signal FB 94
0 = binector B0000
1 = binector B0001
etc.
All binector numbers
1
Ind: None
FS=0
Type: L2
P052 = 3
P051 = 40
Offline
