Siemens 6RA7086-6KS22

Parameter list 05.05
11-120 SIEMENS AG 6RX1700-0AD76
SIMOREG DC Master Operating Instructions
PNU Description Value range
[Unit]
Steps
No. indices
Factory
setting
Type
See
Change
(Access /
Status)
Connector changeover switches 6 and 11
U250
(2250)
*
S00
(B150)
Source for input quantities FB 95 and FB 196
Output 6 = Connector K9215
i001: 1st input signal
i002: 2nd input signal
Output 11 = Connector K9265 [SW2.0 and later]
i003: 1st input signal
i004: 2nd input signal
Settings:
0 = Connector K0000
1 = Connector K0001
etc.
All connector
numbers
1
Ind: 4
FS=0
Type: L2
P052 = 3
P051 = 40
Offline
U251
(2251)
*
S00
(B150)
Source for control signal FB 95 and FB 196
i001: Switchover for output 6
i002: Switchover for output 11 [SW2.0 and later]
Settings:
0 = Binector B0000
1 = Binector B0001
etc.
All binector numbers
1
Ind: 2
FS=0
Type: L2
P052 = 3
P051 = 40
Offline
Connector changeover switches 7 and 12
U252
(2252)
*
S00
(B150)
Source for input quantities FB 96 and FB 197
Output 7 = Connector K9216
i001: 1st input signal
i002: 2nd input signal
Output 12 = Connector K9266 [SW2.0 and later]
i003: 1st input signal
i004: 2nd input signal
Settings:
0 = Connector K0000
1 = Connector K0001
etc.
All connector
numbers
1
Ind: 4
FS=0
Type: L2
P052 = 3
P051 = 40
Offline
U253
(2253)
*
S00
(B150)
Source for control signal FB 96 and FB 197
i001: Switchover for output 7
i002: Switchover for output 12 [SW2.0 and later]
Settings:
0 = Binector B0000
1 = Binector B0001
etc.
All binector numbers
1
Ind: 2
FS=0
Type: L2
P052 = 3
P051 = 40
Offline
Connector changeover switches 8 and 13
U254
(2254)
*
S00
(B150)
Source for input quantities FB 97 and FB 198
Output 8 = Connector K9217
i001: 1st input signal
i002: 2nd input signal
Output 13 = Connector K9267 [SW2.0 and later]
i003: 1st input signal
i004: 2nd input signal
Settings:
0 = Connector K0000
1 = Connector K0001
etc.
All connector
numbers
1
Ind: 4
FS=0
Type: L2
P052 = 3
P051 = 40
Offline
U255
(2255)
*
S00
(B150)
Source for control signal FB 97 and FB 198
i001: Switchover for output 8
i002: Switchover for output 13 [SW2.0 and later]
Settings:
0 = Binector B0000
1 = Binector B0001
etc.
All binector numbers
1
Ind: 2
FS=0
Type: L2
P052 = 3
P051 = 40
Offline
