05.05 Parameter list
SIEMENS AG 6RX1700-0AD76 11-121
SIMOREG DC Master Operating Instructions
PNU Description Value range
[Unit]
Steps
No. indices
Factory
setting
Type
See
Change
(Access /
Status)
Connector changeover switches 9 and 14
U256
(2256)
*
S00
(B150)
Source for input quantities FB 98 and FB 199
Output 9 = Connector K9218
i001: 1st input signal
i002: 2nd input signal
Output 14 = Connector K9268 [SW2.0 and later]
i003: 1st input signal
i004: 2nd input signal
Settings:
0 = Connector K0000
1 = Connector K0001
etc.
All connector
numbers
1
Ind: 4
FS=0
Type: L2
P052 = 3
P051 = 40
Offline
U257
(2257)
*
S00
(B150)
Source for control signal FB 98 and FB 199
i001: Switchover for output 9
i002: Switchover for output 14 [SW2.0 and later]
Settings:
0 = Binector B0000
1 = Binector B0001
etc.
All binector numbers
1
Ind: 2
FS=0
Type: L2
P052 = 3
P051 = 40
Offline
Connector changeover switches 10 and 15
U258
(2258)
*
S00
(B150)
Source for input quantities FB 99 and FB 229
Output 10 = Connector K9219
i001: 1st input signal
i002: 2nd input signal
Output 15 = Connector K9269 [SW2.0 and later]
i003: 1st input signal
i004: 2nd input signal
Settings:
0 = Connector K0000
1 = Connector K0001
etc.
All connector
numbers
1
Ind: 4
FS=0
Type: L2
P052 = 3
P051 = 40
Offline
U259
(2259)
*
S00
(B150)
Source for control signal FB 99 and FB 229
i001: Switchover for output 10
i002: Switchover for output 15 [SW2.0 and later]
Settings:
0 = Binector B0000
1 = Binector B0001
etc.
All binector numbers
1
Ind: 2
FS=0
Type: L2
P052 = 3
P051 = 40
Offline
11.64 Integrators, DT1 elements, characteristics, dead zones, setpoint branching
Only active with optional technology software S00
Integrator 1 (output = K9220)
U260
(2260)
*
S00
(B155)
Source for input quantity FB 100
0 = connector K0000
1 = connector K0001
etc.
All connector
numbers
1
Ind: None
FS=0
Type: L2
P052 = 3
P051 = 40
Offline
U261
(2261)
S00
(B155)
Integral-action time FB 100
10 to 65000
[ms]
1
Ind: None
FS=10
Type: O2
P052 = 3
P051 = 40
Online
