Siemens 6RA7086-6KS22

Parameter list 05.05
11-122 SIEMENS AG 6RX1700-0AD76
SIMOREG DC Master Operating Instructions
PNU Description Value range
[Unit]
Steps
No. indices
Factory
setting
Type
See
Change
(Access /
Status)
U262
(2262)
*
S00
(B155)
Source for control signals FB 100
i001 Source for "Stop integrator" signal
(integrator is stopped when binector reaches log. "1" state)
i002 Source for "Set integrator" signal
(when binector reaches log. "1" state, the integrator is set to the
value entered in parameter U263)
Settings:
0 = binector B0000
1 = binector B0001
etc.
All binector numbers
1
Ind: 2
FS=0
Type: L2
P052 = 3
P051 = 40
Offline
U263
(2263)
*
S00
(B155)
Source for setting value FB 100
0 = connector K0000
1 = connector K0001
etc.
All connector
numbers
1
Ind: None
FS=0
Type: L2
P052 = 3
P051 = 40
Offline
Integrator 2 (output = K9221)
U264
(2264)
*
S00
(B155)
Source for input quantity FB 101
0 = connector K0000
1 = connector K0001
etc.
All connector
numbers
1
Ind: None
FS=0
Type: L2
P052 = 3
P051 = 40
Offline
U265
(2265)
S00
(B155)
Integral-action time FB 101
10 to 65000
[ms]
1
Ind: None
FS=10
Type: O2
P052 = 3
P051 = 40
Online
U266
(2266)
*
S00
(B155)
Source for control signals FB 101
i001 Source for "Stop integrator" signal
(integrator is stopped when binector reaches log. "1" state)
i002 Source for "Set integrator" signal
(when binector reaches log. "1" state, the integrator is set to the
value entered in parameter U267)
Settings:
0 = binector B0000
1 = binector B0001
etc.
All binector numbers
1
Ind: 2
FS=0
Type: L2
P052 = 3
P051 = 40
Offline
U267
(2267)
*
S00
(B155)
Source for setting value FB 101
0 = connector K0000
1 = connector K0001
etc.
All connector
numbers
1
Ind: None
FS=0
Type: L2
P052 = 3
P051 = 40
Offline
Integrator 3 (output = K9222)
U268
(2268)
*
S00
(B155)
Source for input quantity FB 102
0 = connector K0000
1 = connector K0001
etc.
All connector
numbers
1
Ind: None
FS=0
Type: L2
P052 = 3
P051 = 40
Offline
U269
(2269)
S00
(B155)
Integral-action time FB 102
10 to 65000
[ms]
1
Ind: None
FS=10
Type: O2
P052 = 3
P051 = 40
Online
U270
(2270)
*
S00
(B155)
Source for control signals FB 102
i001 Source for "Stop integrator" signal
(integrator is stopped when binector reaches log. "1" state)
i002 Source for "Set integrator" signal
(when binector reaches log. "1" state, the integrator is set to the
value entered in parameter U271)
Settings:
0 = binector B0000
1 = binector B0001
etc.
All binector numbers
1
Ind: 2
FS=0
Type: L2
P052 = 3
P051 = 40
Offline
