05.05 Parameter list
SIEMENS AG 6RX1700-0AD76 11-125
SIMOREG DC Master Operating Instructions
PNU Description Value range
[Unit]
Steps
No. indices
Factory
setting
Type
See
Change
(Access /
Status)
Characteristic block 2 (output = K9230) FB 107
Characteristic block 6 (output = K9412) [SW1.8 and later] FB 282
Characteristic block 7 (output = K9413) [SW1.8 and later] FB 283
U284
(2284)
*
S00
(B160)
Source for input quantity
0 = Connector K0000
1 = Connector K0001
etc.
up to SW 1.7:
Selected connector = input quantity for FB107
SW 1.8 and later:
i001 input quantity for FB107
i002 input quantity for FB282
i003 input quantity for FB283
All connector
numbers
1
Ind: 3
FS=0
Type: L2
P052 = 3
P051 = 40
off-line
U285
(2285)
S00
(B160)
x values
i001 1st characteristic point for FB107
i002 2nd characteristic point for FB107
...
i010 10th characteristic point for FB107
SW 1.8 and later:
i011 1st characteristic point for FB282
i012 2nd characteristic point for FB282
...
i020 10th characteristic point for FB282
i021 1st characteristic point for FB283
i022 2nd characteristic point for FB283
...
i030 10th characteristic point for FB283
-200.00 to 199.99
[%]
0.01
Ind: 30
FS=0.00
Type: I2
P052 = 3
P051 = 40
on-line
U286
(2286)
S00
(B160)
y values
i001 1st characteristic point for FB107
i002 2nd characteristic point for FB107
...
i010 10th characteristic point for FB107
SW 1.8 and later:
i011 1st characteristic point for FB282
i012 2nd characteristic point for FB282
...
i020 10th characteristic point for FB282
i021 1st characteristic point for FB283
i022 2nd characteristic point for FB283
...
i030 10th characteristic point for FB283
-200.00 to 199.99
[%]
0.01
Ind: 30
FS=0.00
Type: I2
P052 = 3
P051 = 40
on-line
Characteristic block 3 (Output = K9231) FB 108
Characteristic block 8 (Output = K9414) [SW1.8 and later] FB 284
Characteristic block 9 (Output = K9415) [SW1.8 and later] FB 285
U287
(2287)
*
S00
(B160)
Source for input quantity
0 = Connector K0000
1 = Connector K0001
etc.
up to SW 1.7:
Selected connector = input quantity for FB108
SW 1.8 and later:
i001 Input quantity for FB108
i002 Input quantity for FB284
i003 Input quantity for FB285
All connector
numbers
1
Ind: 3
FS=0
Type: L2
P052 = 3
P051 = 40
off-line
