Siemens 6RA7086-6KS22

Parameter list 05.05
11-126 SIEMENS AG 6RX1700-0AD76
SIMOREG DC Master Operating Instructions
PNU Description Value range
[Unit]
Steps
No. indices
Factory
setting
Type
See
Change
(Access /
Status)
U288
(2288)
S00
(B160)
x values
i001 1st characteristic point for FB108
i002 2nd characteristic point for FB108
...
i010 10th characteristic point for FB108
SW 1.8 and later:
i011 1st characteristic point for FB284
i012 2nd characteristic point for FB284
...
i020 10th characteristic point for FB284
i021 1st characteristic point for FB285
i022 2nd characteristic point for FB285
...
i030 10th characteristic point for FB285
-200.00 to 199.99
[%]
0.01
Ind: 30
FS=0.00
Type: I2
P052 = 3
P051 = 40
on-line
U289
(2289)
S00
(B160)
y values
i001 1st characteristic point for FB108
i002 2nd characteristic point for FB108
...
i010 10th characteristic point for FB108
SW 1.8 and later:
i011 1st characteristic point for FB284
i012 2nd characteristic point for FB284
...
i020 10th characteristic point for FB284
i021 1st characteristic point for FB285
i022 2nd characteristic point for FB285
...
i030 10th characteristic point for FB285
-200.00 to 199.99
[%]
0.01
Ind: 30
FS=0.00
Type: I2
P052 = 3
P051 = 40
on-line
Dead zones
The component of the input quantity (x) whose absolute value exceeds the threshold for the dead zone is applied to the output (y).
Dead zone 1 (output = K9232)
U290
(2290)
*
S00
(B161)
Source for input quantity FB 109
0 = connector K0000
1 = connector K0001
etc.
All connector
numbers
1
Ind: None
FS=0
Type: L2
P052 = 3
P051 = 40
Offline
U291
(2291)
S00
(B161)
Dead zone FB 109
0.00 to 100.00
[%]
0.01
Ind: None
FS=0.00
Type: O2
P052 = 3
P051 = 40
Online
Dead zone 2 (output = K9233)
U292
(2292)
*
S00
(B161)
Source for input quantity FB 110
0 = connector K0000
1 = connector K0001
etc.
All connector
numbers
1
Ind: None
FS=0
Type: L2
P052 = 3
P051 = 40
Offline
U293
(2293)
S00
(B161)
Dead zone FB 110
0.00 to 100.00
[%]
0.01
Ind: None
FS=0.00
Type: O2
P052 = 3
P051 = 40
Online
Dead zone 3 (output = K9234)
U294
(2294)
*
S00
(B161)
Source for input quantity FB 111
0 = connector K0000
1 = connector K0001
etc.
All connector
numbers
1
Ind: None
FS=0
Type: L2
P052 = 3
P051 = 40
Offline
U295
(2295)
S00
(B161)
Dead zone FB 111
0.00 to 100.00
[%]
0.01
Ind: None
FS=0.00
Type: O2
P052 = 3
P051 = 40
Online
