U313
(2313)
*
S00
(B195)
Source for input quantities for 3rd multiplexer [SW 1.8 and later]
0 = Connector K0000
1 = Connector K0001
etc.
i001 Input quantity X0
i002 Input quantity X1
i003 Input quantity X2
i004 Input quantity X3
i005 Input quantity X4
i006 Input quantity X5
i007 Input quantity X6
i008 Input quantity X7
All connector
numbers
1
Ind: 8
FS=0
Type: L2
P052 = 3
P051 = 40
off-line
11.67 Counters
Only active with optional technology software S00
Software counter FB 89
n314
(2314)
S00
(B196)
Display of output of software counter FB 89
[SW 1.9 and later]
0 to 65535 Ind: None
Type: O2
P052 = 3
U315
(2315)
*
S00
(B196)
Fixed values for setting/limiting inputs of software counter FB 89
[SW 1.9 and later]
i001: Minimum value
i002: Maximum value
i003: Setting value
i004: Start value
0 to 65535
1
Ind: 4
FS=
i001: 0
i002: 65535
i003: 0
i004: 0
Type: O2
P052 = 3
P051 = 40
off-line
U316
(2316)
*
S00
(B196)
Source for setting/limiting inputs of software counter FB 89
[SW 1.9 and later]
i001: Minimum value
i002: Maximum value
i003: Setting value
i004: Start value
Settings:
0 = connector K0000
1 = connector K0001
etc.
All connector
numbers
1
Ind: 4
FS=
i001: 9441
i002: 9442
i003: 9443
i004: 9444
Type: L2
P052 = 3
P051 = 40
off-line
U317
(2317)
*
S00
(B196)
Source for control signals of software counter FB 89
[SW 1.9 and later]
i001: Positive edge: Count up
i002: Positive edge: Count down
i003: Stop counter
i004: Set counter
i005: Enable counter
Settings:
0 = binector B0000
1 = binector B0001
etc.
All binector numbers
1
Ind: 5
FS=
i001: 0
i002: 0
i003: 0
i004: 0
i005: 1
Type: L2
P052 = 3
P051 = 40
