SIMOREG DC Master Operating Instructions
PNU Description Value range
[Unit]
Steps
No. indices
Factory
setting
Type
See
Change
(Access /
Status)
11.68 Logic functions
Only active with optional technology software S00
Decoders/demultiplexers, binary to 1 of 8
U318
(2318)
*
S00
(B200)
Source for input signals for decoder/demultiplexer 1 FB 118
i001 Source for input signal, bit 0
i002 Source for input signal, bit 1
i003 Source for input signal, bit 2
Settings:
0 = binector B0000
1 = binector B0001
etc.
All binector numbers
1
Ind: 3
FS=0
Type: L2
P052 = 3
P051 = 40
Offline
U319
(2319)
*
S00
(B200)
Source for input signals for decoder/demultiplexer 2 FB 119
i001 Source for input signal, bit 0
i002 Source for input signal, bit 1
i003 Source for input signal, bit 2
Settings:
0 = binector B0000
1 = binector B0001
etc.
All binector numbers
1
Ind: 3
FS=0
Type: L2
P052 = 3
P051 = 40
Offline
AND elements with 3 inputs each
The input signals selected via the 3 indices of the parameter are ANDed and the result of the logic operation applied to the specified
binector.
U320
(2320)
*
S00
(B205)
Source for input signals, AND element 1 (output = B9350) FB 120
i001 Source for input 1
i002 Source for input 2
i003 Source for input 3
Settings:
0 = binector B0000
1 = binector B0001
etc.
All binector numbers
1
Ind: 3
FS=1
Type: L2
P052 = 3
P051 = 40
Offline
U321
(2321)
*
S00
(B205)
Source for input signals, AND element 2 (output = B9351) FB 121
As for U320
All binector numbers
1
Ind: 3
FS=1
Type: L2
P052 = 3
P051 = 40
Offline
U322
(2322)
*
S00
(B205)
Source for input signals, AND element 3 (output = B9352) FB 122
As for U320
All binector numbers
1
Ind: 3
FS=1
Type: L2
P052 = 3
P051 = 40
Offline
U323
(2323)
*
S00
(B205)
Source for input signals, AND element 4 (output = B9353) FB 123
As for U320
All binector numbers
1
Ind: 3
FS=1
Type: L2
P052 = 3
P051 = 40
Offline
U324
(2324)
*
S00
(B205)
Source for input signals, AND element 5 (output = B9354) FB 124
As for U320
All binector numbers
1
Ind: 3
FS=1
Type: L2
P052 = 3
P051 = 40
Offline
U325
(2325)
*
S00
(B205)
Source for input signals, AND element 6 (output = B9355) FB 125
As for U320
All binector numbers
1
Ind: 3
FS=1
Type: L2
P052 = 3
P051 = 40
Offline
U326
(2326)
*
S00
(B205)
Source for input signals, AND element 7 (output = B9356) FB 126
As for U320
All binector numbers
1
Ind: 3
FS=1
Type: L2
P052 = 3
P051 = 40
Offline
