Parameter list 05.05
11-134 SIEMENS AG 6RX1700-0AD76
SIMOREG DC Master Operating Instructions
PNU Description Value range
[Unit]
Steps
No. indices
Factory
setting
Type
See
Change
(Access /
Status)
U369
(2369)
*
S00
(B206)
Source for input signals, OR element 20 (output = B9399) FB 169
As for U350
All binector numbers
1
Ind: 3
FS=0
Type: L2
P052 = 3
P051 = 40
Offline
EXCLUSIVE OR elements with 2 inputs each
The input signals selected via the 2 indices of the parameter are combined in an EXCLUSIVE OR (XOR) operation and the result applied
to the specified binector..
U370
(2370)
*
S00
(B206)
Source for input signals, XOR element 1 (output = B9195) FB 170
i001 Source for input 1
i002 Source for input 2
Settings:
0 = binector B0000
1 = binector B0001
etc.
All binector numbers
1
Ind: 2
FS=0
Type: L2
P052 = 3
P051 = 40
Offline
U371
(2371)
*
S00
(B206)
Source for input signals, XOR element 2 (output = B9196) FB 171
As for U370
All binector numbers
1
Ind: 2
FS=0
Type: L2
P052 = 3
P051 = 40
Offline
U372
(2372)
*
S00
(B206)
Source for input signals, XOR element 3 (output = B9197) FB 172
As for U370
All binector numbers
1
Ind: 2
FS=0
Type: L2
P052 = 3
P051 = 40
Offline
U373
(2373)
*
S00
(B206)
Source for input signals, XOR element 4 (output = B9198) FB 173
As for U370
All binector numbers
1
Ind: 2
FS=0
Type: L2
P052 = 3
P051 = 40
Offline
Inverters
The input signal is inverted and the result applied to the specified binector.
U380
(2380)
*
S00
(B207)
Source for input signal, inverter 1 (output = B9450) FB 180
0 = binector B0000
1 = binector B0001
etc.
All binector numbers
1
Ind: None
FS=0
Type: L2
P052 = 3
P051 = 40
Offline
U381
(2381)
*
S00
(B207)
Source for input signal, inverter 2 (output = B9451) FB 181
As for U380
All binector numbers
1
Ind: None
FS=0
Type: L2
P052 = 3
P051 = 40
Offline
U382
(2382)
*
S00
(B207)
Source for input signal, inverter 3 (output = B9452) FB 182
As for U380
All binector numbers
1
Ind: None
FS=0
Type: L2
P052 = 3
P051 = 40
Offline
U383
(2383)
*
S00
(B207)
Source for input signal, inverter 4 (output = B9453) FB 183
As for U380
All binector numbers
1
Ind: None
FS=0
Type: L2
P052 = 3
P051 = 40
Offline
U384
(2384)
*
S00
(B207)
Source for input signal, inverter 5 (output = B9454) FB 184
As for U380
All binector numbers
1
Ind: None
FS=0
Type: L2
P052 = 3
P051 = 40
Offline
U385
(2385)
*
S00
(B207)
Source for input signal, inverter 6 (output = B9455) FB 185
As for U380
All binector numbers
1
Ind: None
FS=0
Type: L2
P052 = 3
P051 = 40
Offline
U386
(2386)
*
S00
(B207)
Source for input signal, inverter 7 (output = B9456) FB 186
As for U380
All binector numbers
1
Ind: None
FS=0
Type: L2
P052 = 3
P051 = 40
Offline
