Siemens 6RA7086-6KS22

05.05 Parameter list
SIEMENS AG 6RX1700-0AD76 11-137
SIMOREG DC Master Operating Instructions
PNU Description Value range
[Unit]
Steps
No. indices
Factory
setting
Type
See
Change
(Access /
Status)
U418
(2418)
*
S00
(B210)
Source for SET and RESET for RS flipflop 4 FB 218
(outputs: Q = B9556, /Q = B9557)
As for U415
All binector numbers
1
Ind: 2
FS=0
Type: L2
P052 = 3
P051 = 40
Offline
U419
(2419)
*
S00
(B210)
Source for SET and RESET for RS flipflop 5 FB 219
(outputs: Q = B9558, /Q = B9559)
As for U415
All binector numbers
1
Ind: 2
FS=0
Type: L2
P052 = 3
P051 = 40
Offline
U420
(2420)
*
S00
(B210)
Source for SET and RESET for RS flipflop 6 FB 220
(outputs: Q = B9560, /Q = B9561)
As for U415
All binector numbers
1
Ind: 2
FS=0
Type: L2
P052 = 3
P051 = 40
Offline
U421
(2421)
*
S00
(B210)
Source for SET and RESET for RS flipflop 7 FB 221
(outputs: Q = B9562, /Q = B9563)
As for U415
All binector numbers
1
Ind: 2
FS=0
Type: L2
P052 = 3
P051 = 40
Offline
U422
(2422)
*
S00
(B210)
Source for SET and RESET for RS flipflop 8 FB 222
(outputs: Q = B9564, /Q = B9565)
As for U415
All binector numbers
1
Ind: 2
FS=0
Type: L2
P052 = 3
P051 = 40
Offline
U423
(2423)
*
S00
(B210)
Source for SET and RESET for RS flipflop 9 FB 223
(outputs: Q = B9566, /Q = B9567)
As for U415
All binector numbers
1
Ind: 2
FS=0
Type: L2
P052 = 3
P051 = 40
Offline
U424
(2424)
*
S00
(B210)
Source for SET and RESET for RS flipflop 10 FB 224
(outputs: Q = B9568, /Q = B9569)
As for U415
All binector numbers
1
Ind: 2
FS=0
Type: L2
P052 = 3
P051 = 40
Offline
U425
(2425)
*
S00
(B210)
Source for SET and RESET for RS flipflop 11 FB 225
(outputs: Q = B9570, /Q = B9571)
As for U415
All binector numbers
1
Ind: 2
FS=0
Type: L2
P052 = 3
P051 = 40
Offline
U426
(2426)
*
S00
(B210)
Source for SET and RESET for RS flipflop 12 FB 226
(outputs: Q = B9572, /Q = B9573)
As for U415
All binector numbers
1
Ind: 2
FS=0
Type: L2
P052 = 3
P051 = 40
Offline
U427
(2427)
*
S00
(B210)
Source for SET and RESET for RS flipflop 13 FB 227
(outputs: Q = B9574, /Q = B9575)
As for U415
All binector numbers
1
Ind: 2
FS=0
Type: L2
P052 = 3
P051 = 40
Offline
U428
(2428)
*
S00
(B210)
Source for SET and RESET for RS flipflop 14 FB 228
(outputs: Q = B9576, /Q = B9577)
As for U415
All binector numbers
1
Ind: 2
FS=0
Type: L2
P052 = 3
P051 = 40
Offline
D flipflops
D flipflops with RESET (Q=0), SET (Q=1) and STORE (Q=D on transition from 0 to 1) (priority: 1
st
RESET, 2
nd
SET, 3
rd
STORE).
RESET setting is enabled on POWER ON.
U430
(2430)
*
S00
(B211)
Source for SET, D, STORE and RESET for D flipflop 1 FB 230
(outputs: Q = B9490, /Q = B9491)
i001 Source for SET
i002 Source for D
i003 Source for STORE
i004 Source for RESET
Settings:
0 = binector B0000
1 = binector B0001
etc.
All binector numbers
1
Ind: 4
FS=0
Type: L2
P052 = 3
P051 = 40
Offline
