Parameter list 05.05
11-136 SIEMENS AG 6RX1700-0AD76
SIMOREG DC Master Operating Instructions
PNU Description Value range
[Unit]
Steps
No. indices
Factory
setting
Type
See
Change
(Access /
Status)
U403
(2403)
*
S00
(B207)
Source for input signals, NAND element 4 (output = B9473) FB 203
As for U400
All binector numbers
1
Ind: 3
FS=1
Type: L2
P052 = 3
P051 = 40
Offline
U404
(2404)
*
S00
(B207)
Source for input signals, NAND element 5 (output = B9474) FB 204
As for U400
All binector numbers
1
Ind: 3
FS=1
Type: L2
P052 = 3
P051 = 40
Offline
U405
(2405)
*
S00
(B207)
Source for input signals, NAND element 6 (output = B9475) FB 205
As for U400
All binector numbers
1
Ind: 3
FS=1
Type: L2
P052 = 3
P051 = 40
Offline
U406
(2406)
*
S00
(B207)
Source for input signals, NAND element 7 (output = B9476) FB 206
As for U400
All binector numbers
1
Ind: 3
FS=1
Type: L2
P052 = 3
P051 = 40
Offline
U407
(2407)
*
S00
(B207)
Source for input signals, NAND element 8 (output = B9477) FB 207
As for U400
All binector numbers
1
Ind: 3
FS=1
Type: L2
P052 = 3
P051 = 40
Offline
U408
(2408)
*
S00
(B207)
Source for input signals, NAND element 9 (output = B9478) FB 208
As for U400
All binector numbers
1
Ind: 3
FS=1
Type: L2
P052 = 3
P051 = 40
Offline
U409
(2409)
*
S00
(B207)
Source for input signals, NAND element 10 (output = B9479) FB 209
As for U400
All binector numbers
1
Ind: 3
FS=1
Type: L2
P052 = 3
P051 = 40
Offline
U410
(2410)
*
S00
(B207)
Source for input signals, NAND element 11 (output = B9480) FB 210
As for U400
All binector numbers
1
Ind: 3
FS=1
Type: L2
P052 = 3
P051 = 40
Offline
U411
(2411)
*
S00
(B207)
Source for input signals, NAND element 12 (output = B9481) FB 211
As for U400
All binector numbers
1
Ind: 3
FS=1
Type: L2
P052 = 3
P051 = 40
Offline
11.69 Storage elements, timers and binary signal selector switches
Only active with optional technology software S00
RS flipflops
RS flipflops with SET (Q=1) and RESET (Q=0) (priority: 1
st
RESET, 2
nd
SET). RESET setting is enabled on POWER ON.
U415
(2415)
*
S00
(B210)
Source for SET and RESET for RS flipflop 1 FB 215
(Outputs: Q = B9550, /Q = B9551)
i001 Source for SET
i002 Source for RESET
Settings:
0 = binector B0000
1 = binector B0001
etc.
All binector numbers
1
Ind: 2
FS=0
Type: L2
P052 = 3
P051 = 40
Offline
U416
(2416)
*
S00
(B210)
Source for SET and RESET for RS flipflop 2 FB 216
(outputs: Q = B9552, /Q = B9553)
As for U415
All binector numbers
1
Ind: 2
FS=0
Type: L2
P052 = 3
P051 = 40
Offline
U417
(2417)
*
S00
(B210)
Source for SET and RESET for RS flipflop 3 FB 217
(outputs: Q = B9554, /Q = B9555)
As for U415
All binector numbers
1
Ind: 2
FS=0
Type: L2
P052 = 3
P051 = 40
Offline
