Siemens 6RA7086-6KS22

05.05 Parameter list
SIEMENS AG 6RX1700-0AD76 11-139
SIMOREG DC Master Operating Instructions
PNU Description Value range
[Unit]
Steps
No. indices
Factory
setting
Type
See
Change
(Access /
Status)
Timer 4 (0.000 to 60.000s) (output = B9586, inverted: B9587)
U449
(2449)
*
S00
(B215)
Source for input signal and reset signal for timer element 4 FB 243
As for U440
All binector numbers
1
Ind: 2
FS=0
Type: L2
P052 = 3
P051 = 40
Offline
U450
(2450)
S00
(B215)
Time for timer 4 FB 243
0.000 to 60.000
[s]
0.001
Ind: None
FS=0.000
Type: O2
P052 = 3
P051 = 40
Offline
U451
(2451)
*
S00
(B215)
Mode for timer 4 FB 243
As for U442
0 to 3
1
Ind: None
FS=0
Type: O2
P052 = 3
P051 = 40
Offline
Timer 5 (0.000 to 60.000s) (output = B9588, inverted: B9589)
U452
(2452)
*
S00
(B215)
Source for input signal and reset signal for timer element 5 FB 244
As for U440
All binector numbers
1
Ind: 2
FS=0
Type: L2
P052 = 3
P051 = 40
Offline
U453
(2453)
S00
(B215)
Time for timer 5 FB 244
0.000 to 60.000
[s]
0.001
Ind: None
FS=0.000
Type: O2
P052 = 3
P051 = 40
Offline
U454
(2454)
*
S00
(B215)
Mode for timer 5 FB 244
As for U442
0 to 3
1
Ind: None
FS=0
Type: O2
P052 = 3
P051 = 40
Offline
Timer 6 (0.000 to 60.000s) (output = B9590, inverted: B9591)
U455
(2455)
*
S00
(B215)
Source for input signal and reset signal for timer element 6 FB 245
As for U440
All binector numbers
1
Ind: 2
FS=0
Type: L2
P052 = 3
P051 = 40
Offline
U456
(2456)
S00
(B215)
Time for timer 6 FB 245
0.000 to 60.000
[s]
0.001
Ind: None
FS=0.000
Type: O2
P052 = 3
P051 = 40
Offline
U457
(2457)
*
S00
(B215)
Mode for timer 6 FB 245
As for U442
0 to 3
1
Ind: None
FS=0
Type: O2
P052 = 3
P051 = 40
Offline
Timer 7 (0.00 to 600.00s) (output = B9592, inverted: B9593)
U458
(2458)
*
S00
(B216)
Source for input signal and reset signal for timer element 7 FB 246
As for U440
All binector numbers
1
Ind: 2
FS=0
Type: L2
P052 = 3
P051 = 40
Offline
U459
(2459)
S00
(B216)
Time for timer 7 FB 246
0.00 to 600.00
[s]
0.01
Ind: None
FS=0.00
Type: O2
P052 = 3
P051 = 40
Offline
U460
(2460)
*
S00
(B216)
Mode for timer 7 FB 246
As for U442
0 to 3
1
Ind: None
FS=0
Type: O2
P052 = 3
P051 = 40
Offline
