Parameter list 05.05
11-140 SIEMENS AG 6RX1700-0AD76
SIMOREG DC Master Operating Instructions
PNU Description Value range
[Unit]
Steps
No. indices
Factory
setting
Type
See
Change
(Access /
Status)
Timer 8 (0.00 to 600.00s) (output = B9594, inverted: B9595)
U461
(2461)
*
S00
(B216)
Source for input signal and reset signal for timer element 8 FB 247
As for U440
All binector numbers
1
Ind: 2
FS=0
Type: L2
P052 = 3
P051 = 40
Offline
U462
(2462)
S00
(B216)
Time for timer 8 FB 247
0.00 to 600.00
[s]
0.01
Ind: None
FS=0.00
Type: O2
P052 = 3
P051 = 40
Offline
U463
(2463)
*
S00
(B216)
Mode for timer 8 FB 247
As for U442
0 to 3
1
Ind: None
FS=0
Type: O2
P052 = 3
P051 = 40
Offline
Timer 9 (0.00 to 600.00s) (output = B9596, inverted: B9597)
U464
(2464)
*
S00
(B216)
Source for input signal and reset signal for timer element 9 FB 248
As for U440
All binector numbers
1
Ind: 2
FS=0
Type: L2
P052 = 3
P051 = 40
Offline
U465
(2465)
S00
(B216)
Time for timer 9 FB 248
0.00 to 600.00
[s]
0.01
Ind: None
FS=0.00
Type: O2
P052 = 3
P051 = 40
Offline
U466
(2466)
*
S00
(B216)
Mode for timer 9 FB 248
As for U442
0 to 3
1
Ind: None
FS=0
Type: O2
P052 = 3
P051 = 40
Offline
Timer 10 (0.00 to 600.00s) (output = B9598, inverted: B9599)
U467
(2467)
*
S00
(B216)
Source for input signal and reset signal for timer element 10 FB 249
As for U440
All binector numbers
1
Ind: 2
FS=0
Type: L2
P052 = 3
P051 = 40
Offline
U468
(2468)
S00
(B216)
Time for timer 10 FB 249
0.00 to 600.00
[s]
0.01
Ind: None
FS=0.00
Type: O2
P052 = 3
P051 = 40
Offline
U469
(2469)
*
S00
(B216)
Mode for timer 10 FB 249
As for U442
0 to 3
1
Ind: None
FS=0
Type: O2
P052 = 3
P051 = 40
Offline
Binary signal selector switches
The control signal (binector) is selected via index i001 of the parameter.
Control signal = 0: Binector as set in index i002 is applied to the output
Control signal = 1: Binector as set in index i003 is applied to the output
U470
(2470)
*
S00
(B216)
Source for input signals for binary signal selector switch 1 FB 250
(output = B9482)
i001 Source for control signal
i002 Source for output signal when control signal = 0
i003 Source for output signal when control signal = 1
Settings:
0 = binector B0000
1 = binector B0001
etc.
All binector numbers
1
Ind: 3
FS=0
Type: L2
P052 = 3
P051 = 40
Offline
U471
(2471)
*
S00
(B216)
Source for input signals for binary signal selector switch 2 FB 251
(output = B9483)
As for U470
All binector numbers
1
Ind: 3
FS=0
Type: L2
P052 = 3
P051 = 40
Offline
