05.05 Parameter list
SIEMENS AG 6RX1700-0AD76 11-141
SIMOREG DC Master Operating Instructions
PNU
Description Value range
[Unit]
Steps
No. indices
Factory
setting
Type
See
Change
(Access /
Status)
U472
(2472)
*
S00
(B216)
Source for input signals for binary signal selector switch 3 FB 252
(output = B9484)
As for U470
All binector numbers
1
Ind: 3
FS=0
Type: L2
P052 = 3
P051 = 40
Offline
U473
(2473)
*
S00
(B216)
Source for input signals for binary signal selector switch 4 FB 253
(output = B9485)
As for U470
All binector numbers
1
Ind: 3
FS=0
Type: L2
P052 = 3
P051 = 40
Offline
U474
(2474)
*
S00
(B216)
Source for input signals for binary signal selector switch 5 FB 254
(output = B9486)
As for U470
All binector numbers
1
Ind: 3
FS=0
Type: L2
P052 = 3
P051 = 40
Offline
11.70 Technology controller
Only active with optional technology software S00
Technology controller: Actual value
U480
(2480)
*
S00
(B170)
Source for actual value FB 114
Selection of connectors to be added as the actual value
0 = connector K0000
1 = connector K0001
etc.
All connector
numbers
1
Ind: 4
FS=0
Type: L2
P052 = 3
P051 = 40
Offline
U481
(2481)
S00
FDS
(B170)
Filter time for actual value FB 114
0.00 to 600.00
[s]
0.01
Ind: 4
FS=0.00
Type: O2
P052 = 3
P051 = 40
Online
U482
(2482)
S00
FDS
(B170)
Derivative-action time for actual value (D component) FB 114
0.000 = D component deactivated
See also U483
0.000 to 30.000
[s]
0.001
Ind: 4
FS=0.000
Type: O2
P052 = 3
P051 = 40
Online
U483
(2483)
*
S00
FDS
(B170)
Factor for derivative-action time FB 114
0 Derivative-action time = U482 * 1
1 Derivative-action time = U482 * 1000
0 to 1
1
Ind: 4
FS=0
Type: O2
P052 = 3
P051 = 40
Offline
Technology controller: Setpoint
U484
(2484)
*
S00
(B170)
Source for setpoint FB 114
Selection of connectors to be added as the setpoint
0 = connector K0000
1 = connector K0001
etc.
All connector
numbers
1
Ind: 4
FS=0
Type: L2
P052 = 3
P051 = 40
Offline
U485
(2485)
S00
FDS
(B170)
Injectable additional setpoint FB 114
This parameter setting is added to the setpoint when the binector selected
in U486 changes to the log. "1" state
-200.00 to 199.99
[%]
0.01
Ind: 4
FS=0.00
Type: I2
P052 = 3
P051 = 40
Online
U486
(2486)
*
S00
(B170)
Source for control bit for injection of additional setpoint FB 114
0 = binector B0000
1 = binector B0001
etc.
All binector numbers
1
Ind: None
FS=0
Type: L2
P052 = 3
P051 = 40
Offline
U487
(2487)
S00
FDS
(B170)
Filter time for setpoint FB 114
0.00 to 600.00
[s]
0.01
Ind: 4
FS=0.00
Type: O2
P052 = 3
P051 = 40
Online
