SIMOREG DC Master Operating Instructions
PNU Description Value range
[Unit]
Steps
No. indices
Factory
setting
Type
See
Change
(Access /
Status)
U509
(2509)
*
S00
(B170)
Source for variable negative limit FB 114
After multiplication with U510, the contents of the selected connector act as
a negative limit for the technology controller output.
0 = connector K0000
1 = connector K0001
etc.
Note:
If the selected connector contains a positive value, a positive minimum
value is applied to the output of this limiter stage.
Note:
Connector K9252 contains the positive limiting value with inverted sign
generated by U507 and U508. By setting U509=9252 and U510=100.00,
therefore, it is possible to set the negative and positive limits symmetrically.
All connector
numbers
1
Ind: None
FS=9252
Type: L2
P052 = 3
P051 = 40
Offline
U510
(2510)
S00
FDS
(B170)
Negative limit for output of technology controller FB 114
See also U509
0.0 to 199.9
[%]
0.1
Ind: 4
FS=100.0
Type: O2
P052 = 3
P051 = 40
Online
U511
(2511)
*
S00
(B170)
Source for variable weighting factor for output FB 114
After multiplication with U512, the contents of the selected connector act as
a weighting factor for the technology controller output.
0 = connector K0000
1 = connector K0001
etc.
All connector
numbers
1
Ind: None
FS=1
Type: L2
P052 = 3
P051 = 40
Offline
U512
(2512)
S00
FDS
(B170)
Weighting factor for output FB 114
See also U511
-100.0 to 100.0
[%]
0.1
Ind: 4
FS=100.0
Type: I2
P052 = 3
P051 = 40
Online
11.71 Velocity/speed calculators
Only active with optional technology software S00
Speed/velocity calculator
Function:
%100
act_n
i
rated_nD
act_v ∗
∗∗
=
π
v_act Actual velocity (n021, U521, K9256)
D Diameter (U517, U518)
n_rated Rated speed (U520)
i Gear ratio (U519)
n_act Actual speed (U515)
U515
(2515)
*
S00
(B190)
Source for actual speed FB 115
0 = connector K0000
1 = connector K0001
etc.
All connector
numbers
1
Ind: None
FS=0
Type: L2
P052 = 3
P051 = 40
Offline
