Siemens 6RA7086-6KS22

05.05 Parameter list
SIEMENS AG 6RX1700-0AD76 11-145
SIMOREG DC Master Operating Instructions
PNU Description Value range
[Unit]
Steps
No. indices
Factory
setting
Type
See
Change
(Access /
Status)
Velocity/speed calculator
Function:
%100
rated_nD
iset_v
set_n ∗
∗∗
∗
=
π
n_set Setpoint speed (n023, K9257)
D Diameter (U517, U518, U523)
n_rated Rated speed (U520)
i Gear ratio (U519)
v_set Setpoint velocity (U516)
U516
(2516)
*
S00
(B190)
Source for set velocity FB 115
A value of 16384 in the selected connector is equivalent to the set velocity
set in U522
0 = Connector K0000
1 = Connector K0001
etc.
All connector
numbers
1
Ind: None
FS=0
Type: L2
P052 = 3
P051 = 40
off-line
U517
(2517)
*
S00
(B190)
Source for diameter FB 115
A value of 16384 in the selected connector is equivalent to the diameter set
in U523
0 = Connector K0000
1 = Connector K0001
etc.
All connector
numbers
1
Ind: None
FS=0
Type: L2
P052 = 3
P051 = 40
off-line
U518
(2518)
S00
FDS
(B190)
Minimum diameter FB 115
Lower limit for diameter set in U517
10.0 to 6553,5
[mm]
0.1
Ind: 4
FS=6500.0
Type: O2
P052 = 3
P051 = 40
Online
U519
(2519)
S00
FDS
(B190)
Gear ratio (i) FB 115
1.00 to 300.00
0.01
Ind: 4
FS=1.00
Type: O2
P052 = 3
P051 = 40
Online
U520
(2520)
S00
FDS
(B190)
Rated speed (n_rated) FB 115
100 to 4000
[rev/m]
1
Ind: 4
FS=1450
Type: O2
P052 = 3
P051 = 40
Online
U521
(2521)
S00
(B190)
Normalization for actual velocity [SW 1.8 and later]
16384 in K9256 correspond to the actual velocity set here
0.01 to 327,67
[m/s]
0.01
Ind: None
FS=16,38
Type: O2
P052 = 3
P051 = 40
on-line
U522
(2522)
S00
(B190)
Normalization for set velocity [SW 1.8 and later]
See parameter U516
0.01 to 327,67
[m/s]
0.01
Ind: None
FS=16,38
Type: O2
P052 = 3
P051 = 40
on-line
U523
(2523)
S00
(B190)
Normalization for diameter [SW 1.8 and later]
See parameter U517
10 to 60000
[mm]
1
Ind: None
FS=1638
Type: O2
P052 = 3
P051 = 40
on-line
