05.05 Parameter list
SIEMENS AG 6RX1700-0AD76 11-149
SIMOREG DC Master Operating Instructions
PNU Description Value range
[Unit]
Steps
No. indices
Factory
setting
Type
See
Change
(Access /
Status)
U541
(2541)
*
S00
(B180...
B189)
Freeze I component [SW 1.8 and later]
0 Controller I component frozen (i.e. pure P controller)
1 Controller I component active
i001: PI controller 1
i002: PI controller 2
...
i010: PI controller 10
0 to 1
1
Ind: 10
FS=1
Type: O2
P052 = 3
P051 = 40
off-line
Output, Limitation
U542
(2542)
*
S00
(B180...
B189)
Source for variable positive limit [SW 1.8 and later]
The content of the selected connector acts as the positive limit for the
output of the PI controller after multiplication with U543.
0 = Connector K0000
1 = Connector K0001
etc.
i001: PI controller 1
i002: PI controller 2
...
i010: PI controller 10
Note:
If the content of the selected connector has a negative value, this causes a
negative maximum value at the output of this limiter stage.
All connector
numbers
1
Ind: 10
FS=1
Type: L2
P052 = 3
P051 = 40
off-line
U543
(2543)
S00
(B180...
B189)
Positive limit for the output of the PI controller [SW 1.8 and later]
See also U542
0.0 to 199.9
[%]
0.1
Ind: 10
FS=100.0
Type: O2
P052 = 3
P051 = 40
on-line
U544
(2544)
*
S00
(B180...
B189)
Source for variable negative Limit [SW 1.8 and later]
The content of the selected connector acts as the negative limit for the
output of the technology controller after multiplication with U510.
0 = Connector K0000
1 = Connector K0001
etc.
i001: PI controller 1
i002: PI controller 2
...
i010: PI controller 10
Note:
If the content of the selected connector has a positive value, this causes a
positive minimum value at the output of this limiter stage.
Note:
Connectors K9306 to K9396 contain for PI controllers 1 to 10 the positive
limitation values formed by U542 and U543 with an inverted sign. In this
way it is possible to set the negative limitation symmetrically to the positive
limitation by setting U544= 9306 to 9396 and U545=100.0.
All connector
numbers
1
Ind: 10
FS=
i001: 9306
i002: 9316
i003: 9326
i004: 9336
i005: 9346
i006: 9356
i007: 9366
i008: 9376
i009: 9386
i010: 9396
Type: L2
P052 = 3
P051 = 40
off-line
U545
(2545)
S00
(B180...
B189)
Negative limit for the output of the PI controller [SW 1.8 and later]
See also U544
0.0 to 199.9
[%]
0.1
Ind: 10
FS=100.0
Type: O2
P052 = 3
P051 = 40
on-line
