Parameter list 05.05
11-158 SIEMENS AG 6RX1700-0AD76
SIMOREG DC Master Operating Instructions
PNU Description Value range
[Unit]
Steps
No. indices
Factory
setting
Type
See
Change
(Access /
Status)
U698
(2698)
(Z135)
(Z136)
(Z145)
(Z146)
Binector selection for binary outputs of SCI [SW 1.9 and later]
Selection of binectors whose states are output via the binary outputs of the
SCIs
i001: Binector selection for SCI slave1, binary output 1
i002: Binector selection for SCI slave1, binary output 2
i003: Binector selection for SCI slave1, binary output 3
i004: Binector selection for SCI slave1, binary output 4
i005: Binector selection for SCI slave1, binary output 5
i006: Binector selection for SCI slave1, binary output 6
i007: Binector selection for SCI slave1, binary output 7
i008: Binector selection for SCI slave1, binary output 8
i009: Binector selection for SCI slave1, binary output 9
i010: Binector selection for SCI slave1, binary output 10
i011: Binector selection for SCI slave1, binary output 11
i012: Binector selection for SCI slave1, binary output12
i013: Binector selection for SCI slave2, binary output 1
i014: Binector selection for SCI slave2, binary output 2
i015: Binector selection for SCI slave2, binary output 3
i016: Binector selection for SCI slave2, binary output 4
i017: Binector selection for SCI slave2, binary output 5
i018: Binector selection for SCI slave2, binary output 6
i019: Binector selection for SCI slave2, binary output 7
i020: Binector selection for SCI slave2, binary output 8
i021: Binector selection for SCI slave2, binary output 9
i022: Binector selection for SCI slave2, binary output 10
i023: Binector selection for SCI slave2, binary output 11
i024: Binector selection for SCI slave2, binary output12
All binector numbers
1
Ind:24
FS= 0
Type L2
P052 = 3
P051 =40
on-line
n699
(2699)
(Z130)
(Z131)
(Z135)
(Z136)
(Z140)
(Z141)
(Z145)
(Z146)
(Z150)
(Z151)
(Z155)
(Z156)
Display of SCB1/SCI process data [SW 1.9 and later]
All values in hexadecimal representation
i001: SCI slave1, binary inputs
i002: SCI slave1, analog input1
i003: SCI slave1, analog input2
i004: SCI slave1, analog input3
i005: SCI slave2, binary inputs
i006: SCI slave2, analog input1
i007: SCI slave2, analog input2
i008: SCI slave2, analog input3
i009: SCI slave1, binary outputs
i010: SCI slave1, analog output1
i011: SCI slave1, analog output2
i012: SCI slave1, analog output3
i013: SCI slave2, binary outputs
i014: SCI slave2, binary outputs
i015: SCI slave2, analog output2
i016: SCI slave2, analog output3
Ind:16
Type L2
P052 = 3
P051 =40
on-line
11.84 Configuration of supplementary boards in board locations 2 and 3
U710
(2710)
*
(Z110)
(Z111)
Initialize link to supplementary boards
i001 Initialization of 1
st
communications board (in slot with lower ID
letter)
i002 Initialization of 2
nd
communications board (in slot with higher ID
letter
Settings:
0 The link to supplementary boards is re-initialized. After the
configuration parameters for supplementary boards have been
changed, U710 must be set to 0 so that the new settings can
take effect.
The parameter is then set automatically to 1.
Note: Data transmission is interrupted while initialization is in
progress.
1 Deactivated
0 to 1
1
Ind: 2
FS=1
Type: O2
P052 = 3
P051 = 40
Offline
