05.05 Parameter list
SIEMENS AG 6RX1700-0AD76 11-157
SIMOREG DC Master Operating Instructions
PNU Description Value range
[Unit]
Steps
No. indices
Factory
setting
Type
See
Change
(Access /
Status)
U695
(2695)
(Z155)
(Z156)
Offset compensation for analog outputs of SCI1 [SW 1.9 and later]
Setting instructions, see Operating Instructions for SCI1
i001: Slave 1, analog output 1
i002: Slave 1, analog output 2
i003: Slave 1, analog output 3
i004: Slave 2, analog output 1
i005: Slave 2, analog output 2
i006: Slave 2, analog output 3
-100.00 to 100.00
[V]
0.01V
Ind:6
FS= 0
Type I2
P052 = 3
P051 =40
on-line
U696
(2696)
Telegram failure time for SCB1 [SW 1.9 and later]
Fault message F079 is displayed if no process data are exchanged with the
supplementary board within this delay period. The monitoring function is
implemented within a 20 ms cycle. For this reason, only setting values
which constitute a multiple of 20 ms are meaningful.
Settings:
0 No time monitoring
1...65000 Permissible time interval between two process data
exchange operations before a fault message is output.
Note:
The telegram monitoring function is active
• from the receipt of the first error-free telegram after connection of the
electronics power supply
• from the receipt of the first error-free telegram after the telegram monitor
has responded (i.e. monitoring timeout).
0 to 65000
[ms]
1ms
Ind: None
FS=0
Type: O2
P052 = 3
P051 =40
Online
n697
(2697)
Diagnostic information of SCB1 [SW 1.9 and later]
Visualization parameter for displaying diagnostic info relating to SCB1.
The displayed values overflow at "255“ (e.g. the number of telegrams begins
at "0" again after "255").
i001: Number of error-free telegrams
i002: Number of errored telegrams
i003: Number of voltage failures on slaves
i004: Number of interruptions in fiber-optic connection
i005: Number of missing response telegrams
i006: Number of search telegrams for slave location
i007: ETX error
i008: Number of configuration telegrams
i009: Highest terminal numbers needed according to PZD
connection (parameterization of connectors or binectors)
i010: Analog inputs/outputs required according to PZD connection of
setpoint channel and actual value output via SCI
(parameterization of appropriate connectors)
i011: Reserved
i012: Reserved
i013: SCB1 alarm word
i014: Setting defining whether slave no. 1 is needed and type if
applicable
0: No slave required
1: SCI1
2: SCI2
i015: Setting defining whether slave no. 2 is needed and type if
applicable
0: No slave required
1: SCI1
2: SCI2
i016: SCI board: Initialization error
i017: SCB1 generation: Year
i018: SCB1 generation: Day and month
i019: SCI slave1: Software version
i020: SCI slave1: Year of generation
i021: SCI slave1: Day and month of generation
i022: SCI slave2: Software version
i023: SCI slave2: Year of generation
i024: SCI slave2: Day and month of generation
Ind:24
Type O2
P052 = 3
P051 =40
on-line
