Siemens 6RA7086-6KS22

Parameter list 05.05
11-156 SIEMENS AG 6RX1700-0AD76
SIMOREG DC Master Operating Instructions
PNU Description Value range
[Unit]
Steps
No. indices
Factory
setting
Type
See
Change
(Access /
Status)
11.83 Configuration of SCB1 with SCI
U690
(2690)
(Z150)
(Z151)
Configuration of analog inputs of SCI1 [SW 1.9 and later]
Definition of type of input signals
Parameter value Terminals Terminals
X428/3, 6, 9 X428/5, 8, 11
0: -10 V ... + 10 V - 20 mA ... + 20 mA
1: 0 V ... + 10 V 0 mA ... + 20 mA
2: 4 mA ... + 20 mA
Notes:
- Only one signal can be processed per input. Voltage or current signals can
be evaluated.
- Voltage and current signals must be connected to different terminals.
- Only unipolar signals are permitted with settings 1 and 2, i.e. the internal
process quantities are also unipolar.
- When setting 2 is selected, an input current of< 2 mA causes shutdown on
faults (open-circuit monitoring)
- The offset compensation for the analog inputs is set in parameter U692.
i001: Slave 1, analog input 1
i002: Slave 1, analog input 2
i003: Slave 1, analog input 3
i004: Slave 2, analog input 1
i005: Slave 2, analog input 2
i006: Slave 2, analog input 3
0 to 2
1
Ind:6
FS= 0
Type O2
P052 = 3
P051 =40
on-line
U691
(2691)
(Z150)
(Z151)
Smoothing time constant for analog inputs of SCI1 [SW 1.9 and later]
Formula: T = 2ms * 2 to the power of U691
i001: Slave 1, analog input 1
i002: Slave 1, analog input 2
i003: Slave 1, analog input 3
i004: Slave 2, analog input 1
i005: Slave 2, analog input 2
i006: Slave 2, analog input 3
0 to 15
1
Ind:6
FS= 2
Type O2
P052 = 3
P051 =40
on-line
U692
(2692)
(Z150)
(Z151)
Offset compensation for analog inputs of SCI1 [SW 1.9 and later]
Setting instructions, see Operating Instructions for SCI1
i001: Slave 1, analog input 1
i002: Slave 1, analog input 2
i003: Slave 1, analog input 3
i004: Slave 2, analog input 1
i005: Slave 2, analog input 2
i006: Slave 2, analog input 3
-20.00 to 20.00
[V]
0.01V
Ind:6
FS= 0
Type I2
P052 = 3
P051 =40
on-line
U693
(2693)
(Z155)
(Z156)
Actual value output via analog outputs of SCI1 [SW 1.9 and later]
Selection of connectors whose values are to be output (for details, see
Operating Instructions for SCI1)
i001: Slave 1, analog output 1
i002: Slave 1, analog output 2
i003: Slave 1, analog output 3
i004: Slave 2, analog output 1
i005: Slave 2, analog output 2
i006: Slave 2, analog output 3
All connector
numbers
1
Ind:6
FS= 0
Type L2
P052 = 3
P051 =40
on-line
U694
(2694)
(Z155)
(Z156)
Gain for analog outputs of SCI1 [SW 1.9 and later]
Setting instructions, see Operating Instructions for SCI1
i001: Slave 1, analog output 1
i002: Slave 1, analog output 2
i003: Slave 1, analog output 3
i004: Slave 2, analog output 1
i005: Slave 2, analog output 2
i006: Slave 2, analog output 3
-320.00 to 320.00
[V]
0.01V
Ind:6
FS= 10.00
Type I2
P052 = 3
P051 =40
on-line
