Siemens 6RA7086-6KS22

05.05 Parameter list
SIEMENS AG 6RX1700-0AD76 11-155
SIMOREG DC Master Operating Instructions
PNU Description Value range
[Unit]
Steps
No. indices
Factory
setting
Type
See
Change
(Access /
Status)
U678
(2678)
*
S00
(B152)
Memory for actual position values: Initial value at POWER ON FB 54
[SW 2.1 and later]
0 Initial value = 0
1 Initial value is set such that on POWER ON KK9481 or KK9482
assumes whatever its setting value was before the electronics
supply was disconnected.
0 to 1
1
Ind: none
FS=0
Type: O2
P052 = 2
P051 = 40
online
11.82 Root extractor
Only active with optional technology software S00
U680
(2680)
*
S00
(B153)
Source for the input of the root extractor FB 58
[SW 2.0 and later]
Selection of the connector whose value is to be used for the root extractor
input.
Settings:
0 = Connector K0000
1 = Connector K0001
etc.
All connector
numbers
1
Ind: none
FS=9483
Type: L2
P052 = 2
P051 = 40
offline
U681
(2681)
S00
(B153)
Operating point for limit monitoring indicator of the root extractor
FB 58
[SW 2.0 and later]
applied to connector KK9483
1 to 65535
1
Ind: none
FS=1
Type: O2
P052 = 2
P051 = 40
online
U682
(2682)
S00
(B153)
Hysteresis for limit monitoring indicator of the root extractor FB 58
[SW 2.0 and later]
1 to 65535
1
Ind: none
FS=1
Type: O2
P052 = 2
P051 = 40
online
U683
(2683)
S00
(B153)
x value for root function and gradient FB 58
[SW 2.0 and later]
Definition of input values
i001: Distance between input value of root function and fictitious
passage through zero for y value U684.001
i002: x value of gradient for y value U684.002
1 to 65535
1
Ind: 2
FS=1000
Type: O2
P052 = 2
P051 = 40
online
U684
(2684)
S00
(B153)
y value for root function and gradient FB 58
[SW 2.0 and later]
Definition of output values
i001: y value of root function for distance U683.001
i002: y value of gradient for x value U683.002
0.01 to 199.99
[%]
0.01
Ind: 2
FS=100.00
Type: O2
P052 = 2
P051 = 40
online
