Parameter list 05.05
11-160 SIEMENS AG 6RX1700-0AD76
SIMOREG DC Master Operating Instructions
PNU
Description Value range
[Unit]
Steps
No. indices
Factory
setting
Type
See
Change
(Access /
Status)
U722
(2722)
*
(Z110)
(Z111)
Telegram failure time for CB and TB
i001: Telegram failure time for board location 2
i002: Telegram failure time for board location 3
i003: Fault delay time for 1
st
CB or TB
i004: Fault delay time for 2
nd
CB
Settings for telegram failure time:
0 No time monitoring; must be parameterized for sporadic
(acyclic) telegrams
1...65500 Maximum permissible time interval between 2 data
exchanges before fault message F082 can be output
Settings for fault delay time:
0 Instantaneous activation of F082
1...65499 Fault delay time before F082 is activated.
65500 F082 is never activated
If no process data are exchanged with the supplementary board for a period
in excess of the telegram failure time, fault message F082 is activated as a
function of the fault delay time.
Monitoring takes place in a 20 ms cycle. For this reason, it is only
meaningful to set values that are multiples of 20 ms.
t [ms]
U722.001
or
U722.002
U722.003
or
U722.004
last
receive
telegram
B3035 = 1
or
B8035 = 1
F082
and
B3030 = 1
B3031 = 1
or
B8030 = 1
B8031 = 1
Note:
The telegram monitoring function is active
• from the receipt of the first error-free telegram after connection of the
electronics power supply
• from the receipt of the first error-free telegram after the telegram monitor
has responded (i.e. monitoring timeout).
0 to 65000
[ms]
1ms
Ind: 4
FS=0
Type: O2
P052 = 3
Online
U723
(2723)
*
Timeout period for technology boards [SW 2.1 and later]
i001: Timeout period until F080 fault value 1 (no heartbeat)
i002: Timeout period until F080 fault value 6 (delay until initialization
is complete).
Additional permissible period after expiry of time set in index
001 for completion of initialization.
Example
U732.001 = 30, U732.002 = 20:
When the electronics supply is switched on, F080 fault value 1 is delayed by
30 s and F080 fault value 6 by 30s + 20s = 50s.
20 to 60
[s]
1s
Ind: 2
FS= 20
Type: O2
P052 = 3
P051 = 40
on-line
U728
(2728)
*
(Z110)
Source for binector/connector converter for 1
st
CB/TB
[SW 1.9 and later]
Binectors to be converted to connector K3020
i001: 1
st
binector (bit 0)
i002: 2
nd
binector (bit 1)
...
i016: 16
th
binector (bit 15)
Settings:
0 = binector B0000
1 = binector B0001
etc.
All binector numbers
1
Ind: 16
FS=0
Type: L2
P052 = 3
P051 = 40
off-line
