Siemens 6RA7086-6KS22

05.05 Parameter list
SIEMENS AG 6RX1700-0AD76 11-161
SIMOREG DC Master Operating Instructions
PNU Description Value range
[Unit]
Steps
No. indices
Factory
setting
Type
See
Change
(Access /
Status)
U729
(2729)
*
(Z111)
Source for binector/connector converter for 2
nd
CB [SW 1.9 and later]
Binectors to be converted to connector K8020
i001: 1st binector (bit 0)
i002: 2
nd
binector (bit 1)
...
i016: 16
th
binector (bit 15)
Settings:
0 = binector B0000
1 = binector B0001
etc.
All binector numbers
1
Ind: 16
FS=0
Type: L2
P052 = 3
P051 = 40
off-line
n732
(2732)
(Z110)
(Z111)
CB/TB diagnostics
Diagnostic information about an installed communications board (CB) or
technology board (TB).
i001 - i032: 1. CB/TB (lower slot ID letter)
i033 - i064: 2. CB (higher slot ID letter)
i065, i066: 1. CB/TB (internal diagnostic data)
i067, i068: 2. CB (internal diagnostic data)
For detailed information, please refer to operating instructions of relevant
CB or TB.
Ind: 68
Type: O2
P052 = 3
n733
(2733)
(Z110)
(Z111)
CB/TB receive data
Display of control words and setpoints (process data) that are transferred to
the basic converter from a communications board (CB) or technology board
(TB).
i001: 1
st
process data word from 1
st
CB/TB
...
i016 16
th
process data word from 1
st
CB/TB
i017: 1
st
process data word from 2
nd
CB
...
i032: 16
th
process data word from 2
nd
CB
Ind: 32
Type: L2
P052 = 3
U734
(2734)
*
(Z110)
Transmit data for first CB/TB (lower slot ID letter)
Selection of connectors whose contents must be injected as transmit data to
the first communications board (CB) or technology board (TB).
0 = connector K0000
1 = connector K0001
etc.
This parameter not only defines the transmit data, but also their position in
the transmit telegram.
i001: Word 1 in PZD section of telegram
i002: Word 2 in PZD section of telegram
...
i016: Word 16 in PZD section of telegram
Status word 1 (K0032) should be linked to word 1.
All connector
numbers
1
Ind: 16
FS=
i001: 32
i002: 167
i003: 0
i004: 33
i005: 0
to
i016: 0
Type: L2
P052 = 3
Online
n735
(2735)
(Z110)
(Z111)
Display of transmit data to CB/TB
i001: 1
st
process data word to 1
st
CB or TB
...
i016 16
th
process data word to 1
st
CB or TB
i017: 1
st
process data word to 2
nd
CB
...
i032: 16
th
process data word to 2
nd
CB
Ind: 32
Type: L2
P052 = 3
