SIMOREG DC Master Operating Instructions
PNU Description Value range
[Unit]
Steps
No. indices
Factory
setting
Type
See
Change
(Access /
Status)
U736
(2736)
*
(Z111)
Transmit data for second CB (higher slot letter)
Selection of connectors whose contents must be injected as transmit data to
a communications board (CB) with a higher slot ID letter.
0 = connector K0000
1 = connector K0001
etc.
This parameter not only defines the transmit data, but also their position in
the transmit telegram.
i001: Word 1 in PZD section of telegram
i002: Word 2 in PZD section of telegram
...
i016: Word 16 in PZD section of telegram
Status word 1 (K0032) should be linked to word 1.
All connector
numbers
1
Ind: 16
FS=0
Type: L2
P052 = 3
Online
n738
(2738)
(Z110)
(Z111)
Display of PKW job from supplementary boards
i001: 1
st
word of PKW job from 1
st
CB
...
i004 4
th
word of PKW job from 1
st
CB
i005: 1
st
word of PKW job from location 2
nd
CB
...
i008 4
th
word of PKW job from 2
nd
CB
i009: 1
st
word of PKW job from TB
...
i012: 4
th
word of PKW job from TB
Details refer to “Function diagrams”, Section 8 Sheets Z110 and Z111
Ind: 12
Type: L2
P052 = 3
n739
(2739)
(Z110)
(Z111)
Display of PKW response to supplementary boards
i001: 1
st
word of PKW job from 1
st
CB
...
i004 4
th
word of PKW job from 1
st
CB
i005: 1
st
word of PKW job from location 2
nd
CB
...
i008 4
th
word of PKW job from 2
nd
CB
i009: 1
st
word of PKW job from TB
...
i012: 4
th
word of PKW job from TB
Details refer to “Function diagrams”, Section 8 Sheets Z110 and Z111
Ind: 12
Type: L2
P052 = 3
11.85 Configuring the SIMOLINK board
U740
(2740)
*
(Z121)
SLB Node address [SW 1.5 and later]
Node address of the SIMOLINK board (SLB) on the bus. The node address
defines the telegrams to which the relevant board has write access. The
node address also defines whether a node is to perform the additional
function of dispatcher.
0 = Dispatcher (generates telegram circulation)
Not 0 = Transceiver
Only one node in a SIMOLINK ring may perform the function of dispatcher.
Node address 0 may not be assigned to any node if a higher-level PLC is
performing the dispatcher function as the SIMOLINK master. When an SLB
is selected to operate as dispatcher, all nodes must be assigned
consecutive addresses, starting with address 0 for the dispatcher.
i001: For first SLB in unit
i002: Reserved
0 to 200
1
Ind: 2
FS=0
Type: O2
P052 = 3
P051 =40
Offline
