05.05 Parameter list
SIEMENS AG 6RX1700-0AD76 11-171
SIMOREG DC Master Operating Instructions
PNU
Description Value range
[Unit]
Steps
No. indices
Factory
setting
Type
See
Change
(Access /
Status)
11.89 Configuration of paralleling interface
Notes about parameterization of the paralleling interface see Chapter 6.3.2
U800
(2800)
*
(G195)
Control word for paralleling interface
0: Paralleling interface not active
1: Paralleling interface active
The gating pulses are generated by this
SIMOREG converter
2: Paralleling interface active
The gating pulses of the master are used
Must also be set if a SIMOREG CCP is used
0 to 2
1
Ind: None
FS=0
Type: O2
P052 = 3
P051 = 40
Offline
U803
(2803)
*
(G195)
Operating mode for the parallel connection [SW 1.7 and later]
0 Standard mode
All parallel-connected SIMOREG devices must be in continuous
operation. Failure (fault message, fuse blown) of one
of the
parallel-connected SIMOREG devices causes immediate pulse
disabling for all
SIMOREG devices.
1 "N+1 mode" (redundancy mode)
On failure (fault message, fuse blown) of one of the parallel-
connected SIMOREG devices, operation is maintained with the
remaining SIMOREG devices.
0 to 1
1
Ind: None
FS=0
Type: O2
P052 = 3
P051 = 40
off-line
U804
(2804)
*
(G195)
Transmit data on paralleling interface
Selection of connectors whose contents must be injected as transmit data
(master to slaves or slave to master) for the paralleling interface.
0 = connector K0000
1 = connector K0001
etc.
This parameter not only defines the transmit data, but also their position in
the transmit telegram.
i001: Word 1 of telegram
...
i005: Word 5 of telegram
i006: word 1 of the telegram, if "standby master" [SW 1.7 and later]
...
i010: word 5 of the telegram, if "standby master" [SW 1.7 and later]
Indices .06 to .10 of U804 are activated on the master and the standby
master when the “master” function is transferred to the standby master
All connector
numbers
1
Ind: 10
FS=0
Type: L2
P052 = 3
P051 = 40
Online
U805
(2805)
(G195)
Control word for bus terminator of paralleling interface
0: No bus terminator
1: Bus terminator active
0 to 1
1
Ind: None
FS=0
Type: O2
P052 = 3
P051 = 40
Online
U806
(2806)
*
(G195)
Address for the parallel connection of SIMOREG devices
i001: Address of the masters or of the slaves
i002: Address of the "standby master" or slaves [SW 1.7 and later]
2: Slave device with address 2
3: Slave device with address 3
4: Slave device with address 4
5: Slave device with address 5
6: Slave device with address 6
12: Master device for 1 slave device with address 2
13: Master device for 2 slave devices with addresses 2 and 3
14: Master device for 3 slave devices with addresses 2, 3 and 4
15: Master device for 4 slave devices with addresses 2, 3, 4 and 5
16: Master device for 5 slave devices with addresses 2, 3, 4, 5 and
6
In "Standard" mode (U803 = 0), i001 and i002 must be set to the same
value.
In "N+1 mode" (U803 = 1), a SIMOREG device has the "master" function, a
SIMOREG device has the "standby Master" function and all other devices
are slaves. In the slaves, i001 and i002 must be set to the same value.
On the master, a value of 12 to 16 must be set in i001, in i002 a value of 2
to 6.
In the "standby master", a value of 2 to 6 must be set in i001, in i002 a value
of 12 to 16.
see column on left Ind: 2
FS=2
Type: O2
P052 = 3
P051 = 40
off-line
