05.05 Parameter list
SIEMENS AG 6RX1700-0AD76 11-173
SIMOREG DC Master Operating Instructions
PNU
Description Value range
[Unit]
Steps
No. indices
Factory
setting
Type
See
Change
(Access /
Status)
n810
(2810)
(G195)
Diagnostic information for the paralleling interface
3210
4
5
6
7
89101112131415
Unit with active “master” function
Segment
0 .......
1 .......
2 ....... ON: Slave with address 2 responding
3 ....... ON: Slave with address 3 responding
4 ....... ON: Slave with address 4 responding
5 ....... ON: Slave with address 5 responding
6 ....... ON: Slave with address 6 responding
7 .......
8 ....... OFF
9 ....... OFF
10 .......
11 .......
12 .......
13 .......
14 .......
15 ....... ON: Master function active
Unit with “slave” function
Segment
0 .......
1 .......
2 ....... ON: Data for slave with address 2 are ok
3 ....... ON: Data for slave with address 3 are ok
4 ....... ON: Data for slave with address 4 are ok
5 ....... ON: Data for slave with address 5 are ok
6 ....... ON: Data for slave with address 6 are ok
7 .......
8 ....... ON: Slave function active
9 ....... ON: Firing pulses of master are used
10 .......
11 .......
12 .......
13 .......
14 .......
15 ....... OFF
Ind: None
Type: V2
P052 = 3
To Next Page
