Parameter list 05.05
11-174 SIEMENS AG 6RX1700-0AD76
SIMOREG DC Master Operating Instructions
PNU Description Value range
[Unit]
Steps
No. indices
Factory
setting
Type
See
Change
(Access /
Status)
n812
(2812)
(G195)
Receive data on paralleling interface
When U806=1 (master) is selected
i001 Receive data from slave with address 2, word 1
...
i005 Receive data from slave with address 2, word 5
i006 Receive data from slave with address 3, word 1
...
i010 Receive data from slave with address 3, word 5
i011 Receive data from slave with address 4, word 1
...
i015 Receive data from slave with address 4, word 5
i016 Receive data from slave with address 5, word 1
...
i020 Receive data from slave with address 5, word 5
i021 Receive data from slave with address 6, word 1
...
i025 Receive data from slave with address 6, word 5
When U806=2 to 6 (slave) is selected
:
i001 Receive data from master, word 1
...
i005 Receive data from master, word 5
i006 Not in use
...
i025 Not in use
0000 to FFFFH
1
Ind: 25
Type: L2
P052
≥ 0
n813
(2813)
(G195)
Transmit data on paralleling interface
When U806=1 (master) is selected
i001 Transmit data to slaves, word 1
...
i005 Transmit data to slaves, word 5
When U806=2 to 6 (slave) is selected:
i001 Transmit data to master, word 1
...
i005 Transmit data to master, word 5
0 to FFFFH Ind: 5
Type: L2
P052
≥ 0
11.90 Parameters for SIMOREG CM (Control Module)
U819
to
U835
(2819 to
2835)
These parameters have no meaning for SIMOREG DC Master!
The SIMOREG CM (Control Module, control section for converting or
upgrading systems) requires these parameters.
(for details see operating instructions for SIMOREG CM, order No.
6RX1700-0BD76)
11.91 Rated DC current of external field device
U838
(2838)
*
Rated DC current of external field device [SW 1.9 and later]
0.00 Parameter not yet set
Note:
This parameter is operative only if P082 >= 21.
0.00 to 600.00
[A]
0.01A
Ind: None
FS=0.00
Type: O2
P052 = 3
P051 = 40
on-line
