05.05 Connectors and binectors
SIEMENS AG 6RX1700-0AD76 12-11
SIMOREG DC Master Operating Instructions
Connector Description Normalization Function
diag., Sheet
K0993
Total processor capacity (C167) currently utilized by routines synchronized
with field firing pulses
K0994
Total processor capacity (C167) currently utilized by routines synchronized
with armature firing pulses
Serial interface 1 (USS1 on G-SST1)
K2001
USS1 receive data, word 1
1
=
∧
1
G170
K2002
USS1 receive data, word 2
1
=
∧
1
G170
K2003
USS1 receive data, word 3
1
=
∧
1
G170
K2004
USS1 receive data, word 4
1
=
∧
1
G170
K2005
USS1 receive data, word 5
1
=
∧
1
G170
K2006
USS1 receive data, word 6
1
=
∧
1
G170
K2007
USS1 receive data, word 7
1
=
∧
1
G170
K2008
USS1 receive data, word 8
1
=
∧
1
G170
K2009
USS1 receive data, word 9
1
=
∧
1
G170
K2010
USS1 receive data, word 10
1
=
∧
1
G170
K2011
USS1 receive data, word 11
1
=
∧
1
G170
K2012
USS1 receive data, word 12
1
=
∧
1
G170
K2013
USS1 receive data, word 13
1
=
∧
1
G170
K2014
USS1 receive data, word 14
1
=
∧
1
G170
K2015
USS1 receive data, word 15
1
=
∧
1
G170
K2016
USS1 receive data, word 16
1
=
∧
1
G170
K2020
Output of binector/connector converter for G-SST1 [SW 1.4 and later]
1
=
∧
1
G170
KK2031
USS1 receive data, word 1 and 2 [SW 2.0 and later]
1
=
∧
1
G169
KK2032
USS1 receive data, word 2 and 3 [SW 2.0 and later]
1
=
∧
1
G169
KK2033
USS1 receive data, word 3 and 4 [SW 2.0 and later]
1
=
∧
1
G169
KK2034
USS1 receive data, word 4 and 5 [SW 2.0 and later]
1
=
∧
1
G169
KK2035
USS1 receive data, word 5 and 6 [SW 2.0 and later]
1
=
∧
1
G169
KK2036
USS1 receive data, word 6 and 7 [SW 2.0 and later]
1
=
∧
1
G169
KK2037
USS1 receive data, word 7 and 8 [SW 2.0 and later]
1
=
∧
1
G169
KK2038
USS1 receive data, word 8 and 9 [SW 2.0 and later]
1
=
∧
1
G169
KK2039
USS1 receive data, word 9 and 10 [SW 2.0 and later]
1
=
∧
1
G169
KK2040
USS1 receive data, word 10 and 11 [SW 2.0 and later]
1
=
∧
1
G169
KK2041
USS1 receive data, word 11 and 12 [SW 2.0 and later]
1
=
∧
1
G169
KK2042
USS1 receive data, word 12 and 13 [SW 2.0 and later]
1
=
∧
1
G169
KK2043
USS1 receive data, word 13 and 14 [SW 2.0 and later]
1
=
∧
1
G169
KK2044
USS1 receive data, word 14 and 15 [SW 2.0 and later]
1
=
∧
1
G169
KK2045
USS1 receive data, word 15 and 16 [SW 2.0 and later]
1
=
∧
1
G169
Process data exchange with 1
st
CB/TB
K3001
Receive data from 1
st
CB/TB, word 1
1
=
∧
1
Z110
K3002
Receive data from 1
st
CB/TB, word 2
1
=
∧
1
Z110
K3003
Receive data from 1
st
CB/TB, word 3
1
=
∧
1
Z110
K3004
Receive data from 1
st
CB/TB, word 4
1
=
∧
1
Z110
K3005
Receive data from 1
st
CB/TB, word 5
1
=
∧
1
Z110
K3006
Receive data from 1
st
CB/TB, word 6
1
=
∧
1
Z110
K3007
Receive data from 1
st
CB/TB, word 7
1
=
∧
1
Z110
K3008
Receive data from 1
st
CB/TB, word 8
1
=
∧
1
Z110
K3009
Receive data from 1
st
CB/TB, word 9
1
=
∧
1
Z110
K3010
Receive data from 1
st
CB/TB, word 10
1
=
∧
1
Z110
