Connectors and binectors 05.05
12-12 SIEMENS AG 6RX1700-0AD76
SIMOREG DC Master Operating Instructions
Connector Description Normalization Function
diag., Sheet
K3011
Receive data from 1
st
CB/TB, word 11
1
=
∧
1
Z110
K3012
Receive data from 1
st
CB/TB, word 12
1
=
∧
1
Z110
K3013
Receive data from 1
st
CB/TB, word 13
1
=
∧
1
Z110
K3014
Receive data from 1
st
CB/TB, word 14
1
=
∧
1
Z110
K3015
Receive data from 1
st
CB/TB, word 15
1
=
∧
1
Z110
K3016
Receive data from 1
st
CB/TB, word 16
1
=
∧
1
Z110
K3020
Output of binector/connector converter for 1
st
CB/TB [SW 1.9 and later]
1
=
∧
1
Z110
KK3031
Receive data from 1
st
CB/TB, word 1 and 2 [SW 2.0 and later]
1
=
∧
1
Z124
KK3032
Receive data from 1
st
CB/TB, word 2 and 3 [SW 2.0 and later]
1
=
∧
1
Z124
KK3033
Receive data from 1
st
CB/TB, word 3 and 4 [SW 2.0 and later]
1
=
∧
1
Z124
KK3034
Receive data from 1
st
CB/TB, word 4 and 5 [SW 2.0 and later]
1
=
∧
1
Z124
KK3035
Receive data from 1
st
CB/TB, word 5 and 6 [SW 2.0 and later]
1
=
∧
1
Z124
KK3036
Receive data from 1
st
CB/TB, word 6 and 7 [SW 2.0 and later]
1
=
∧
1
Z124
KK3037
Receive data from 1
st
CB/TB, word 7 and 8 [SW 2.0 and later]
1
=
∧
1
Z124
KK3038
Receive data from 1
st
CB/TB, word 8 and 9 [SW 2.0 and later]
1
=
∧
1
Z124
KK3039
Receive data from 1
st
CB/TB, word 9 and 10 [SW 2.0 and later]
1
=
∧
1
Z124
KK3040
Receive data from 1
st
CB/TB, word 10 and 11 [SW 2.0 and later]
1
=
∧
1
Z124
KK3041
Receive data from 1
st
CB/TB, word 11 and 12 [SW 2.0 and later]
1
=
∧
1
Z124
KK3042
Receive data from 1
st
CB/TB, word 12 and 13 [SW 2.0 and later]
1
=
∧
1
Z124
KK3043
Receive data from 1
st
CB/TB, word 13 and 14 [SW 2.0 and later]
1
=
∧
1
Z124
KK3044
Receive data from 1
st
CB/TB, word 14 and 15 [SW 2.0 and later]
1
=
∧
1
Z124
KK3045
Receive data from 1
st
CB/TB, word 15 and 16 [SW 2.0 and later]
1
=
∧
1
Z124
SCB1 with SCI1
K4101
SCI, slave 1, analog input 1 [SW 1.9 and later]
1
=
∧
1
Z150
K4102
SCI, slave 1, analog input 2 [SW 1.9 and later]
1
=
∧
1
Z150
K4103
SCI, slave 1, analog input 3 [SW 1.9 and later]
1
=
∧
1
Z150
K4201
SCI, slave 2, analog input 1 [SW 1.9 and later]
1
=
∧
1
Z151
K4202
SCI, slave 2, analog input 2 [SW 1.9 and later]
1
=
∧
1
Z151
K4203
SCI, slave 2, analog input 3 [SW 1.9 and later]
1
=
∧
1
Z151
Expansion boards [SW 1.5 and later]
K5101
1st analog input of 1st plugged EB1
16384
=
∧
100%
Z112
K5102
2nd analog input of 1st plugged EB1
16384
=
∧
100%
Z112
K5103
3rd analog input of 1st plugged EB1
16384
=
∧
100%
Z112
K5104
1st analog output of 1st plugged EB1
16384
=
∧
100%
Z113
K5105
2nd analog output of 1st plugged EB1
16384
=
∧
100%
Z113
K5106
Binary inputs and outputs of 1st plugged EB1
1
=
∧
1
Z114
K5111
Analog input of 1st plugged EB2
16384
=
∧
100%
Z118
K5112
Analog output of 1st plugged EB2
16384
=
∧
100%
Z118
K5113
Binary inputs and outputs of 1st plugged EB2
1
=
∧
1
Z118
K5201
1st analog input of 2nd plugged EB1
16384
=
∧
100%
Z115
K5202
2nd analog input of 2nd plugged EB1
16384
=
∧
100%
Z115
K5203
3rd analog input of 2nd plugged EB1
16384
=
∧
100%
Z115
K5204
1st analog output of 2nd plugged EB1
16384
=
∧
100%
Z116
K5205
2nd analog output of 2nd plugged EB1
16384
=
∧
100%
Z116
K5206
Binary inputs and outputs of 2nd plugged EB1
1
=
∧
1
Z117
K5211
Analog input of 2nd plugged EB2
16384
=
∧
100%
Z119
K5212
Analog output of 2nd plugged EB2
16384
=
∧
100%
Z119
K5213
Binary inputs and outputs of 2nd plugged EB2
1
=
∧
1
Z119
