05.05 Connectors and binectors
SIEMENS AG 6RX1700-0AD76 12-13
SIMOREG DC Master Operating Instructions
Connector Description Normalization Function
diag., Sheet
Serial interface 2 (USS2 / Peer-to-peer 2 on G-SST2)
K6001
USS2 / Peer2 receive data, word 1
1
=
∧
1
G171, G173
K6002
USS2 / Peer2 receive data, word 2
1
=
∧
1
G171, G173
K6003
USS2 / Peer2 receive data, word 3
1
=
∧
1
G171, G173
K6004
USS2 / Peer2 receive data, word 4
1
=
∧
1
G171, G173
K6005
USS2 / Peer2 receive data, word 5
1
=
∧
1
G171, G173
K6006
USS2 receive data, word 6
1
=
∧
1
G171
K6007
USS2 receive data, word 7
1
=
∧
1
G171
K6008
USS2 receive data, word 8
1
=
∧
1
G171
K6009
USS2 receive data, word 9
1
=
∧
1
G171
K6010
USS2 receive data, word 10
1
=
∧
1
G171
K6011
USS2 receive data, word 11
1
=
∧
1
G171
K6012
USS2 receive data, word 12
1
=
∧
1
G171
K6013
USS2 receive data, word 13
1
=
∧
1
G171
K6014
USS2 receive data, word 14
1
=
∧
1
G171
K6015
USS2 receive data, word 15
1
=
∧
1
G171
K6016
USS2 receive data, word 16
1
=
∧
1
G171
K6020
Output of binector/connector converter for G-SST2 [SW 1.4 and later]
1
=
∧
1
G171, G173
Paralleling interface
K6021
Word 1 from master / Word 1 from slave with address 2
1
=
∧
1
G195
K6022
Word 2 from master / Word 2 from slave with address 2
1
=
∧
1
G195
K6023
Word 3 from master / Word 3 from slave with address 2
1
=
∧
1
G195
K6024
Word 4 from master / Word 4 from slave with address 2
1
=
∧
1
G195
K6025
Word 5 from master / Word 5 from slave with address 2
1
=
∧
1
G195
K6031
Word 1 from slave with address 3
1
=
∧
1
G195
K6032
Word 2 from slave with address 3
1
=
∧
1
G195
K6033
Word 3 from slave with address 3
1
=
∧
1
G195
K6034
Word 4 from slave with address 3
1
=
∧
1
G195
K6035
Word 5 from slave with address 3
1
=
∧
1
G195
K6041
Word 1 from slave with address 4
1
=
∧
1
G195
K6042
Word 2 from slave with address 4
1
=
∧
1
G195
K6043
Word 3 from slave with address 4
1
=
∧
1
G195
K6044
Word 4 from slave with address 4
1
=
∧
1
G195
K6045
Word 5 from slave with address 4
1
=
∧
1
G195
K6051
Word 1 from slave with address 5
1
=
∧
1
G195
K6052
Word 2 from slave with address 5
1
=
∧
1
G195
K6053
Word 3 from slave with address 5
1
=
∧
1
G195
K6054
Word 4 from slave with address 5
1
=
∧
1
G195
K6055
Word 5 from slave with address 5
1
=
∧
1
G195
K6061
Word 1 from slave with address 6
1
=
∧
1
G195
K6062
Word 2 from slave with address 6
1
=
∧
1
G195
K6063
Word 3 from slave with address 6
1
=
∧
1
G195
K6064
Word 4 from slave with address 6
1
=
∧
1
G195
K6065
Word 5 from slave with address 6
1
=
∧
1
G195
Serial interface 2 (USS2 / Peer-to-peer 2 on G-SST2)
KK6081
USS2 / Peer2 receive data, word 1 and 2 [SW 2.0 and later]
1
=
∧
1
G169
KK6082
USS2 / Peer2 receive data, word 2 and 3 [SW 2.0 and later]
1
=
∧
1
G169
