Connectors and binectors 05.05
12-14 SIEMENS AG 6RX1700-0AD76
SIMOREG DC Master Operating Instructions
Connector Description Normalization Function
diag., Sheet
KK6083
USS2 / Peer2 receive data, word 3 and 4 [SW 2.0 and later]
1
=
∧
1
G169
KK6084
USS2 / Peer2 receive data, word 4 and 5 [SW 2.0 and later]
1
=
∧
1
G169
KK6085
USS2 receive data, word 5 and 6 [SW 2.0 and later]
1
=
∧
1
G169
KK6086
USS2 receive data, word 6 and 7 [SW 2.0 and later]
1
=
∧
1
G169
KK6087
USS2 receive data, word 7 and 8 [SW 2.0 and later]
1
=
∧
1
G169
KK6088
USS2 receive data, word 8 and 9 [SW 2.0 and later]
1
=
∧
1
G169
KK6089
USS2 receive data, word 9 and 10 [SW 2.0 and later]
1
=
∧
1
G169
KK6090
USS2 receive data, word 10 and 11 [SW 2.0 and later]
1
=
∧
1
G169
KK6091
USS2 receive data, word 11 and 12 [SW 2.0 and later]
1
=
∧
1
G169
KK6092
USS2 receive data, word 12 and 13 [SW 2.0 and later]
1
=
∧
1
G169
KK6093
USS2 receive data, word 13 and 14 [SW 2.0 and later]
1
=
∧
1
G169
KK6094
USS2 receive data, word 14 and 15 [SW 2.0 and later]
1
=
∧
1
G169
KK6095
USS2 receive data, word 15 and 16 [SW 2.0 and later]
1
=
∧
1
G169
Process data exchange with SIMOLINK [SW 1.5 and later]
K7001
Receive data from SIMOLINK, word 1
1
=
∧
1
Z122
K7002
Receive data from SIMOLINK, word 2
1
=
∧
1
Z122
K7003
Receive data from SIMOLINK, word 3
1
=
∧
1
Z122
K7004
Receive data from SIMOLINK, word 4
1
=
∧
1
Z122
K7005
Receive data from SIMOLINK, word 5
1
=
∧
1
Z122
K7006
Receive data from SIMOLINK, word 6
1
=
∧
1
Z122
K7007
Receive data from SIMOLINK, word 7
1
=
∧
1
Z122
K7008
Receive data from SIMOLINK, word 8
1
=
∧
1
Z122
K7009
Receive data from SIMOLINK, word 9
1
=
∧
1
Z122
K7010
Receive data from SIMOLINK, word 10
1
=
∧
1
Z122
K7011
Receive data from SIMOLINK, word 11
1
=
∧
1
Z122
K7012
Receive data from SIMOLINK, word 12
1
=
∧
1
Z122
K7013
Receive data from SIMOLINK, word 13
1
=
∧
1
Z122
K7014
Receive data from SIMOLINK, word 14
1
=
∧
1
Z122
K7015
Receive data from SIMOLINK, word 15
1
=
∧
1
Z122
K7016
Receive data from SIMOLINK, word 16
1
=
∧
1
Z122
KK7031
Receive data from SIMOLINK, word 1 and 2 [SW 2.0 and later]
1
=
∧
1
Z124
KK7032
Receive data from SIMOLINK, word 2 and 3 [SW 2.0 and later]
1
=
∧
1
Z124
KK7033
Receive data from SIMOLINK, word 3 and 4 [SW 2.0 and later]
1
=
∧
1
Z124
KK7034
Receive data from SIMOLINK, word 4 and 5 [SW 2.0 and later]
1
=
∧
1
Z124
KK7035
Receive data from SIMOLINK, word 5 and 6 [SW 2.0 and later]
1
=
∧
1
Z124
KK7036
Receive data from SIMOLINK, word 6 and 7 [SW 2.0 and later]
1
=
∧
1
Z124
KK7037
Receive data from SIMOLINK, word 7 and 8 [SW 2.0 and later]
1
=
∧
1
Z124
K7101
Receive data from SIMOLINK, special data word 1
1
=
∧
1
Z122
K7102
Receive data from SIMOLINK, special data word 2
1
=
∧
1
Z122
K7103
Receive data from SIMOLINK, special data word 3
1
=
∧
1
Z122
K7104
Receive data from SIMOLINK, special data word 4
1
=
∧
1
Z122
K7105
Receive data from SIMOLINK, special data word 5
1
=
∧
1
Z122
K7106
Receive data from SIMOLINK, special data word 6
1
=
∧
1
Z122
K7107
Receive data from SIMOLINK, special data word 7
1
=
∧
1
Z122
K7108
Receive data from SIMOLINK, special data word 8
1
=
∧
1
Z122
KK7131
Receive data from SIMOLINK, special data word 1 and 2 [SW 2.0 and later]
1
=
∧
1
Z124
KK7132
Receive data from SIMOLINK, special data word 2 and 3 [SW 2.0 and later]
1
=
∧
1
Z124
KK7133
Receive data from SIMOLINK, special data word 3 and 4 [SW 2.0 and later]
1
=
∧
1
Z124
