Connectors and binectors 05.05
12-16 SIEMENS AG 6RX1700-0AD76
SIMOREG DC Master Operating Instructions
Connector Description Normalization Function
diag., Sheet
K9011
USS3 receive data, word 11
1
=
∧
1
G172
K9012
USS3 receive data, word 12
1
=
∧
1
G172
K9013
USS3 receive data, word 13
1
=
∧
1
G172
K9014
USS3 receive data, word 14
1
=
∧
1
G172
K9015
USS3 receive data, word 15
1
=
∧
1
G172
K9016
USS3 receive data, word 16
1
=
∧
1
G172
K9020
Output of binector/connector converter for G-SST3 [SW 1.4 and later]
1
=
∧
1
G172, G174
KK9081
USS3 / Peer3 receive data, word 1 and 2 [SW 2.0 and later]
1
=
∧
1
G169
KK9082
USS3 / Peer3 receive data, word 2 and 3 [SW 2.0 and later]
1
=
∧
1
G169
KK9083
USS3 / Peer3 receive data, word 3 and 4 [SW 2.0 and later]
1
=
∧
1
G169
KK9084
USS3 / Peer3 receive data, word 4 and 5 [SW 2.0 and later]
1
=
∧
1
G169
KK9085
USS3 receive data, word 5 and 6 [SW 2.0 and later]
1
=
∧
1
G169
KK9086
USS3 receive data, word 6 and 7 [SW 2.0 and later]
1
=
∧
1
G169
KK9087
USS3 receive data, word 7 and 8 [SW 2.0 and later]
1
=
∧
1
G169
KK9088
USS3 receive data, word 8 and 9 [SW 2.0 and later]
1
=
∧
1
G169
KK9089
USS3 receive data, word 9 and 10 [SW 2.0 and later]
1
=
∧
1
G169
KK9090
USS2 receive data, word 10 and 11 [SW 2.0 and later]
1
=
∧
1
G169
KK9091
USS3 receive data, word 11 and 12 [SW 2.0 and later]
1
=
∧
1
G169
KK9092
USS3 receive data, word 12 and 13 [SW 2.0 and later]
1
=
∧
1
G169
KK9093
USS3 receive data, word 13 and 14 [SW 2.0 and later]
1
=
∧
1
G169
KK9094
USS3 receive data, word 14 and 15 [SW 2.0 and later]
1
=
∧
1
G169
KK9095
USS3 receive data, word 15 and 16 [SW 2.0 and later]
1
=
∧
1
G169
Technology software S00: Binector/connector converters
K9113
Output of binector/connector converter 1 FB 13
1
=
∧
1
B121
K9114
Output of binector/connector converter 2 FB 14
1
=
∧
1
B121
K9115
Output of binector/connector converter 3 FB 15
1
=
∧
1
B121
Technology software S00: Adders / Subtracters
K9120
Output of adder/subtracter 1 FB 20
16384
=
∧
100%
B125
K9121
Output of adder/subtracter 2 FB 21
16384
=
∧
100%
B125
K9122
Output of adder/subtracter 3 FB 22
16384
=
∧
100%
B125
K9123
Output of adder/subtracter 4 FB 23
16384
=
∧
100%
B125
K9124
Output of adder/subtracter 5 FB 24
16384
=
∧
100%
B125
K9125
Output of adder/subtracter 6 FB 25
16384
=
∧
100%
B125
K9126
Output of adder/subtracter 7 FB 26
16384
=
∧
100%
B125
K9127
Output of adder/subtracter 8 FB 27
16384
=
∧
100%
B125
K9128
Output of adder/subtracter 9 FB 28
16384
=
∧
100%
B125
K9129
Output of adder/subtracter 10 FB 29
16384
=
∧
100%
B125
K9130
Output of adder/subtracter 11 FB 30
16384
=
∧
100%
B125
K9131
Output of adder/subtracter 12 FB 31
16384
=
∧
100%
B125
K9132
Output of adder/subtracter 13 [SW 1.8 and later] FB 32
16384
=
∧
100%
B125
K9133
Output of adder/subtracter 14 [SW 1.8 and later] FB 33
16384
=
∧
100%
B125
K9134
Output of adder/subtracter 15 [SW 1.8 and later] FB 34
16384
=
∧
100%
B125
Technology software S00: Sign inverters, switchable sign inverters
K9135
Output of sign inverter 1 FB 35
16384
=
∧
100%
B125
K9136
Output of sign inverter 2 FB 36
16384
=
∧
100%
B125
K9137
Output of sign inverter 3 FB 37
16384
=
∧
100%
B125
K9138
Output of sign inverter 4 FB 38
16384
=
∧
100%
B125
