05.05 Connectors and binectors
SIEMENS AG 6RX1700-0AD76 12-17
SIMOREG DC Master Operating Instructions
Connector Description Normalization Function
diag., Sheet
K9140
Output of switchable sign inverter 1 FB 40
16384
=
∧
100%
B125
K9141
Output of switchable sign inverter 2 FB 41
16384
=
∧
100%
B125
Technology software S00: Dividers, multipliers, high-resolution multipliers/dividers
K9142
Output of divider 4 [SW 1.8 and later] FB 42
16384
=
∧
100%
B131
K9143
Output of divider 5 [SW 1.8 and later] FB 43
16384
=
∧
100%
B131
K9144
Output of divider 6 [SW 1.8 and later] FB 44
16384
=
∧
100%
B131
K9145
Output of divider 1 FB 45
16384
=
∧
100%
B131
K9146
Output of divider 2 FB 46
16384
=
∧
100%
B131
K9147
Output of divider 3 FB 47
16384
=
∧
100%
B131
K9150
Output of multiplier 1 FB 50
16384
=
∧
100%
B130
K9151
Output of multiplier 2 FB 51
16384
=
∧
100%
B130
K9152
Output of multiplier 3 FB 52
16384
=
∧
100%
B130
K9153
Output of multiplier 4 FB 53
16384
=
∧
100%
B130
K9155
Output of high-resolution multiplier/divider 1 FB 55
16384
=
∧
100%
B131
K9156
Output of high-resolution multiplier/divider 2 FB 56
16384
=
∧
100%
B131
K9157
Output of high-resolution multiplier/divider 3 FB 57
16384
=
∧
100%
B131
Technology software S00: Absolute-value generator with filter
K9160
Output of absolute-value generator with filter 1 FB 60
16384
=
∧
100%
B135
K9161
Output of absolute-value generator with filter 2 FB 61
16384
=
∧
100%
B135
K9162
Output of absolute-value generator with filter 3 FB 62
16384
=
∧
100%
B135
K9163
Output of absolute-value generator with filter 4 FB 63
16384
=
∧
100%
B135
Technology software S00: Limiters
K9165
Limiter 1: Fixed limiting value FB 65
16384
=
∧
100%
B135
K9166
Limiter 1: Positive limiting value * (-1) FB 65
16384
=
∧
100%
B135
K9167
Limiter 1: Output FB 65
16384
=
∧
100%
B135
K9168
Limiter 2: Fixed limiting value FB 66
16384
=
∧
100%
B135
K9169
Limiter 2: Positive limiting value * (-1) FB 66
16384
=
∧
100%
B135
K9170
Limiter 2: Output FB 66
16384
=
∧
100%
B135
K9171
Limiter 3: Fixed limiting value FB 67
16384
=
∧
100%
B135
K9172
Limiter 3: Positive limiting value * (-1) FB 67
16384
=
∧
100%
B135
K9173
Limiter 3: Output FB 67
16384
=
∧
100%
B135
K9174
Limiter 4: Fixed limiting value [SW 2.0 and later] FB 212
16384
=
∧
100%
B134
K9175
Limiter 4: Positive limiting value * (-1) [SW 2.0 and later] FB 212
16384
=
∧
100%
B134
K9176
Limiter 4: Output [SW 2.0 and later] FB 212
16384
=
∧
100%
B134
K9177
Limiter 5: Fixed limiting value [SW 2.0 and later] FB 213
16384
=
∧
100%
B134
K9178
Limiter 5: Positive limiting value * (-1) [SW 2.0 and later] FB 213
16384
=
∧
100%
B134
K9179
Limiter 5: Output [SW 2.0 and later] FB 213
16384
=
∧
100%
B134
Technology software S00: Limit-value monitor with filter
K9180
Limit-value monitor with filter 1: Filtered input quantity FB 70
16384
=
∧
100%
B136
K9181
Limit-value monitor with filter 1: Fixed operating point FB 70
16384
=
∧
100%
B136
K9182
Limit-value monitor with filter 2: Filtered input quantity FB 71
16384
=
∧
100%
B136
K9183
Limit-value monitor with filter 2: Fixed operating point FB 71
16384
=
∧
100%
B136
K9184
Limit-value monitor with filter 3: Filtered input quantity FB 72
16384
=
∧
100%
B136
K9185
Limit-value monitor with filter 3: Fixed operating point FB 72
16384
=
∧
100%
B136
