05.05 Connectors and binectors
SIEMENS AG 6RX1700-0AD76 12-19
SIMOREG DC Master Operating Instructions
Connector Description Normalization Function
diag., Sheet
Technology software S00: Dead zones
K9232
Output of dead zone 1 FB 109
16384
=
∧
100%
B161
K9233
Output of dead zone 2 FB 110
16384
=
∧
100%
B161
K9234
Output of dead zone 3 FB 111
16384
=
∧
100%
B161
Technology software S00: Setpoint branching
K9235
Setpoint branching output FB 112
16384
=
∧
100%
B161
Technology software S00: Simple ramp-function generator
K9236
Simple ramp-function generator output FB 113
16384
=
∧
100%
B165
Technology software S00: Technology controller
K9240
Technology controller, signed actual value FB 114
16384
=
∧
100%
B170
K9241
Technology controller, absolute actual value FB 114
16384
=
∧
100%
B170
K9242
D component FB 114
16384
=
∧
100%
B170
K9243
Technology controller, setpoint FB 114
16384
=
∧
100%
B170
K9244
Technology controller, filtered setpoint FB 114
16384
=
∧
100%
B170
K9245
Setpoint/actual value deviation FB 114
16384
=
∧
100%
B170
K9246
Setpoint/actual value deviation after droop FB 114
16384
=
∧
100%
B170
K9247
P component FB 114
16384
=
∧
100%
B170
K9248
I component FB 114
16384
=
∧
100%
B170
K9249
Technology controller output before limitation FB 114
16384
=
∧
100%
B170
K9250
Positive limit for technology controller output FB 114
16384
=
∧
100%
B170
K9251
Negative limit for technology controller output FB 114
16384
=
∧
100%
B170
K9252
Positive limit for technology controller output * (-1) FB 114
16384
=
∧
100%
B170
K9253
Technology controller output after limitation FB 114
16384
=
∧
100%
B170
K9254
Technology controller output after multiplication with weighting factor FB 114
16384
=
∧
100%
B170
Technology software S00: Speed/velocity calculator, velocity/speed calculator
K9256
Speed/velocity calculator: Actual velocity FB 115
16384
=
∧
100%
B190
K9257
Velocity/speed calculator: Speed setpoint FB 115
16384
=
∧
100%
B190
Technology software S00: Variable moment of inertia [SW 1.8 and later] FB 116
K9258
Variable moment of inertia (output)
16384
=
∧
100%
B191
Technology software S00: Limiters
K9260
Limiter 6: Fixed limiting value [SW 2.0 and later] FB 214
16384
=
∧
100%
B134
K9261
Limiter 6: Positive limiting value * (-1) [SW 2.0 and later] FB 214
16384
=
∧
100%
B134
K9262
Limiter 6: Output [SW 2.0 and later] FB 214
16384
=
∧
100%
B134
Technology software S00: Connector changeover switches
K9265
Output connector changeover switch 11 [SW 2.0 and later] FB 196
16384
=
∧
100%
B150
K9266
Output connector changeover switch 12 [SW 2.0 and later] FB 197
16384
=
∧
100%
B150
K9267
Output connector changeover switch 13 [SW 2.0 and later] FB 198
16384
=
∧
100%
B150
K9268
Output connector changeover switch 14 [SW 2.0 and later] FB 199
16384
=
∧
100%
B150
K9269
Output connector changeover switch 15 [SW 2.0 and later] FB 229
16384
=
∧
100%
B150
Technology software S00: PI controller 1 [SW 1.8 and later] FB260
K9300
Input quantity filtered
16384
=
∧
100%
B180
K9301
P component
16384
=
∧
100%
B180
