Siemens 6RA7086-6KS22

Connectors and binectors 05.05
12-20 SIEMENS AG 6RX1700-0AD76
SIMOREG DC Master Operating Instructions
Connector Description Normalization Function
diag., Sheet
K9302
I component
16384
=
∧
100%
B180
K9303
Output PI controller before limitation
16384
=
∧
100%
B180
K9304
Output PI controller after limitation
16384
=
∧
100%
B180
K9305
Positive limit for the output of the PI controller
16384
=
∧
100%
B180
K9306
Positive limit for the output of the PI controller (K9305)
∗ -1
16384
=
∧
100%
B180
K9307
Negative limit for the output of the PI controller
16384
=
∧
100%
B180
Technology software S00: PI controller 2 [SW 1.8 and later] FB261
K9310
Input quantity filtered
16384
=
∧
100%
B181
K9311
P component
16384
=
∧
100%
B181
K9312
I component
16384
=
∧
100%
B181
K9313
Output PI controller before limitation
16384
=
∧
100%
B181
K9314
Output PI controller after limitation
16384
=
∧
100%
B181
K9315
Positive limit for the output of the PI controller
16384
=
∧
100%
B181
K9316
Positive limit for the output of the PI controller (K9315)
∗ -1
16384
=
∧
100%
B181
K9317
Negative limit for the output of the PI controller
16384
=
∧
100%
B181
Technology software S00: PI controller 3 [SW 1.8 and later] FB262
K9320
Input quantity filtered
16384
=
∧
100%
B182
K9321
P component
16384
=
∧
100%
B182
K9322
I component
16384
=
∧
100%
B182
K9323
Output PI controller before limitation
16384
=
∧
100%
B182
K9324
Output PI controller after limitation
16384
=
∧
100%
B182
K9325
Positive limit for the output of the PI controller
16384
=
∧
100%
B182
K9326
Positive limit for the output of the PI controller (K9325)
∗ -1
16384
=
∧
100%
B182
K9327
Negative limit for the output of the PI controller
16384
=
∧
100%
B182
Technology software S00: PI controller 4 [SW 1.8 and later] FB263
K9330
Input quantity filtered
16384
=
∧
100%
B183
K9331
P component
16384
=
∧
100%
B183
K9332
I component
16384
=
∧
100%
B183
K9333
Output PI controller before limitation
16384
=
∧
100%
B183
K9334
Output PI controller after limitation
16384
=
∧
100%
B183
K9335
Positive limit for the output of the PI controller
16384
=
∧
100%
B183
K9336
Positive limit for the output of the PI controller (K9335)
∗ -1
16384
=
∧
100%
B183
K9337
Negative limit for the output of the PI controller
16384
=
∧
100%
B183
Technology software S00: PI controller 5 [SW 1.8 and later] FB264
K9340
Input quantity filtered
16384
=
∧
100%
B184
K9341
P component
16384
=
∧
100%
B184
K9342
I component
16384
=
∧
100%
B184
K9343
Output PI controller before limitation
16384
=
∧
100%
B184
K9344
Output PI controller after limitation
16384
=
∧
100%
B184
K9345
Positive limit for the output of the PI controller
16384
=
∧
100%
B184
K9346
Positive limit for the output of the PI controller (K9345)
∗ -1
16384
=
∧
100%
B184
K9347
Negative limit for the output of the PI controller
16384
=
∧
100%
B184
Technology software S00: PI controller 6 [SW 1.8 and later] FB265
K9350
Input quantity filtered
16384
=
∧
100%
B185
K9351
P component
16384
=
∧
100%
B185
